Stainless Steel Cr Sheet Galvanized Sheet Cutting to Length Machine Ce Certificated
| US$12,000.00-18,000.00 | 1 set (MOQ) |
Basic Info.
Model NO.
customized
Drive Mode
CNC
Warranty
1 Year
Customized
Customized
Layout
Horizontal
Cutting Material
Carbon Steel, Aluminum, Metal Alloy, Stainless Steel
Automatic Grade
Automatic
Power Source
Electric
Cutting Mode
Waterjet Cutting
Application
for Cold Rolled Steel Coil, Galvanzied
Thickness
0.3mm to 1.8mm
Width
400mm to 1000mm
Coil ID
508mm
Coil Od
No More Than 1500mm
Coil Weight
10ton Max
Sheets Length
500mm ~ 5000mm
Stacking Height
Max 400mm
Stacking Weight
Max 5000kg
Transport Package
Sea Shipping
Specification
20′′ container
Trademark
SENERGE
Origin
Shanghai, China
Production Capacity
3 Unit/ Month
Product Description
Stainless Steel CR Sheet Galvanized Sheet Cutting to length Machine CE certificated
1.1 Input Material
Cold rolled steel coil, Galvanized steel ,coil,Stainless steel
Thickness: 0.4mm to 3.0mm
Width: 1000mm to 1600mm
Coil ID: 508mm/610mm
Coil OD: ≤Φ1600mm
Coil weight:15,000kg Max
1.2 Cut to Length Performance
Sheets length: 300mm ~4000mm
Length Tolerance: +/-0.5mm (For Length 2000mm)
Diagonal Accuracy: ≤+/-0.8mm/2m (JIS standard sheet)
Flatness: ≤3I (JIS standard sheet)
Stacking Weight: 5T
1.3 Slitting Performance
Strips Number (related to the thickness of the strip):
7 cuts(thickness 3mm)
14 cuts(thickness 2mm)
Width Accuracy: 0.1mm
Cutting Burr: 5% sheet thickness,
Slitting Straightness: 0.5mm/1000mm
Recoiling Weight: Max 15T (DIA<1600)
