Closely hermetic Dehumidification system Plastic Drying Conveying Machine Industrial Dryer
| US$29,800.00-36,600.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
SLHJ-2000L/1500H-1
Warranty
1 Year
Capacity
2000L
Dry Blower
1500m³/hr
Power of Heater
36kw
Pipe Diameter
51mm
Transport Package
Standard Export Packing
Specification
2300x2400x2300mm
Trademark
MFGSP
Origin
China
HS Code
8419399090
Production Capacity
5000sets/Year
Packaging & Delivery
Package Size
230.00cm * 240.00cm * 230.00cm
Package Gross Weight
480.000kg
Product Description
Combination of Drying,Dehumidifying and Conveying
Performance characteristic:
1.Combine the three functions of Drying ,Dehumidifying and Conveying into one. Also can make the equipment convey the materials onto three hoppers according to customer's requirements.
2.The dehumidification system is designed to be closely hermetic,which ensures the air of low dew point doesn't contact with the outside air.
3.The conveying system is designed to be closely hermetic,which ensures the dried material not contactiong with the outside air and being wet again.
4.The shut off valve is equipped on the conveying system to ensure no remnant materials in the material pipeline and smooth conveying.
5.Double-layer heat preservation dry barrel to effective prevent the heat loss and save energy consumption.
6.High efficient heat dissipater to ensure the air with lower temperature and lower dew point.
Specifications:
| Model | Capacity (L) | Dry Blower (m³/hr) | Power of Heater (kw) | Power of Dry Blower (kw) | Power of Regenrating blower (kw) | Power of Air Pump (kw) | Power of Regenrating Heater (kw) | Pipe Diameter (mm) | External Dimensions LxWxH(mm) |
| SLHJ- 40L/80 | 40 | 80 | 4 | 0.55 | 0.18 | 1.1 | 1.5 | 38 | 1160x745x1450 |
| SLHJ- 80L/80 | 80 | 80 | 4 | 0.55 | 0.18 | 1.1 | 1.5 | 38 | 1220x745x1550 |
| SLHJ-120L/100 | 120 | 100 | 6 | 1.5 | 0.25 | 1.1 | 2 | 38 | 1320x840x1680 |
| SLHJ-160L/100 | 160 | 100 | 9 | 1.5 | 0.25 | 1.1 | 2 | 38 | 1370x840x1720 |
| SLHJ-230L/120 | 230 | 120 | 9 | 1.5 | 0.25 | 1.5 | 3 | 38 | 1500x900x1880 |
| SLHJ-300L/150 | 300 | 150 | 12 | 1.5 | 0.55 | 1.5 | 3 | 38 | 1520x1900x1930 |
| SLHJ-380L/200 | 380 | 200 | 14.5 | 2.2 | 0.55 | 1.5 | 3 | 38 | 900x1500x1450 |
| SLHJ-460L/300 | 460 | 300 | 14.5 | 3 | 0.55 | 1.5 | 3 | 38 | 1100x1650x1550 |
| SLHJ-600L/400 | 600 | 400 | 18 | 4 | 0.55 | 2.2 | 4 | 38 | 1100x1650x1550 |
| SLHJ-800L/500 | 800 | 500 | 18 | 5.5 | 0.75 | 2.2 | 4 | 51 | 1750x1900x1900 |
| SLHJ-1000L/700 | 1000 | 700 | 24 | 7.5 | 0.75 | 2.2 | 5 | 51 | 1750x1900x1900 |
| SLHJ-1200L/700 | 1200 | 700 | 24 | 7.5 | 0.75 | 2.2 | 5 | 51 | 1800x2200x2100 |
| SLHJ-1300L/1000H | 1300 | 1000 | 24 | 4X2 | 1.1 | 3 | 7 | 51 | 2100x2200x2100 |
| SLHJ-1600L/1000H | 1600 | 1000 | 36 | 4X2 | 1.1 | 3 | 7 | 51 | 2100x2200x2300 |
| SLHJ-2000L/1500H | 2000 | 1500 | 36 | 5.5X2 | 1.1 | 5.5 | 7X2 | 51 | 2300x2400x2300 |
| SLHJ-2600L/1500H | 2600 | 1500 | 42 | 5.5X2 | 1.1 | 5.5 | 7X2 | 51 | 2300x2400x2400 |
| SLHJ-3300L/2000H | 3300 | 2000 | 42 | 7.5X2 | 1.5 | 7.5 | 7X2 | 51 | 2500x2600x2500 |
| SLHJ-4000L/2000H | 4000 | 2000 | 42 | 7.5X2 | 1.5 | 7.5 | 7X2 | 51 | 2500x2600x2700 |
Diagram of installation:
