Ivo M084gns1 R1 8.4 Inch TFT LCD Screen 800X600

Product Description

Medical Display IVO 800x600 LVDS interface M084GNS1 R1 SVGA 8.4 inch tft lcd panel screen
Description:

Manufacturer	IVO
Model Name	M084GNS1 R1
Screen Size	8.4 inch
Screen Type	a-Si TFT-LCD, LCM
Pixel Number	800(RGB)×600 [SVGA]
Arrangement	RGB Vertical Stripe
Active Area(mm)	170.4(H)×127.8(V) mm
Outline(mm)	203(H)×142.5(V) ×6.2(D) mm
Bezel Area(mm)	173.4(H)×131.2(V) mm
Surface	Antiglare, Hard coating (3H)
Brightness	350 cd/m² (Typ.)
Contrast Ratio	600:1 (Typ.) (TM)
Viewing Angle	80/80/80/80 (Typ.)(CR≥10) Left/Right/Up/ Down
Response	16 (Typ.)(Tr+Td)
Good View at	12 o'clock
Work Mode	TN, Normally White, Transmissive
Color Depth	262K/16.7M 45% (CIE1931)
Backlight	WLED [8S4P] , 50K hours , With LED Driver
Net Weight	200/220g (Typ./Max.)
Used for	Industrial Application
operating frequency	60Hz
Touchscreen	without
Interface Type	20 pins LVDS (1 ch, 6/8-bit) , Connector
Voltage Supply	3.3V (Typ.)
Max. Ratings	Storage Temperature: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
RoHS Compliance	RoHS Compliance
Aspect Ratio	4:3 (H:V)
Package	Original package; 40 pcs / box

Common Applications

Telecommunication Devices	Telephone,interphone,watch,tablet PC,radio,etc
Consumer Products	Camera,DVD player,toy, Cell Phone,game player,etc
Technical Equipment	Elevator controller,Industrial machine,etc
Office Automation	Printer,scanner,attendance machine,fax machine,etc
Home Appliances	Air-condition display,refrigerator,electric cooker,video doorbell,etc
Automobile	GPS,video player,speedometer,audio broadcast,etc
IT Products	Camera,handheld digital video,projector,media play,tablet PC,etc
Medical Equipment	Ultrasound machine,therapeutic equipment Blood pressure meter,etc

Advantages
1.LCD&LCM Display: Design, Manufacturing LCD&LCM (TN, STN, CSTN, TFT); OEM Service for COG, TAB & COB LCD Modules.
2.Guarantee: In order to ensure our products' quality, each process has been aranged QC. And there are many advanced machines introduced to check the products quality. The goods will have a ramdom test before delivery. One year for warranty under normal use.
Service Related Types and Customized Services TFT LCM Module Standard and custom make from 0.95" TFT to 27.0" TFT Resistive Touch Panel and Capacitive Touch Panels Standard and custom design Resistive,Capacitive Touch Panels and IR touch screens from 1.44" to 65.0" TFT Module with Capacitive Touch Assembly Standard and custom design Capacitive Touch CTP+TFT module from 1.44" to 19.0" TFT Controller Board Standard and custom make TFT Driving Board from 2.4" to 13.3" Raspberry Pi 4B and TFT Display Kits Development PCBA Board with Embeded System, Support OS Android, Linux, Windows what services can we provide Customise Resistive and Capacitive Touch Panels as you requirements Customise AG, AR, AF, AS, Cover lens Add NTSC, PAL, VGA, HDMI Conversion Board and T-Con Board Custmise the luminance of LED backlight for particular models,FPC Length, Sunlight Readable. Accepted Delivery Terms: FOB;EXW;CIF Accepted Payment Currency:USD,CNY; Accepted Payment Type: T/T,Cash;Paypal,Western Union. Language Spoken:English,Chinese
