CNC Connecter Cutting Saw for Aluminum Profile Window and Door Processing

Product Description

Key attributes
Equipment attributes

Equipment name	CNC Corner Connector Cutting Saw
Model	LJMJ-CNC-450/500

Technical Parameter

Power supply	380V/50Hz
Power	3.0KW
Motor Speed	3850r/min
Working pressure	0.6~0.8MPa
Blade size	φ450/φ500*φ30*4.4mm
Sawing range	155*170mm
Dimensions	1400*1400*1800mm
Warranty	1 year

Lead time

Quantity(sets)	1-1	>1
Lead time(days)	20	To be negotiated

Customization

Customized logo	Min. order: 1 set
Customized packaging Graphic customization	Min. order: 1 set Min. order: 1 set
For more customization details,message supplier

Certifications
* This machine features simple operation, reliable performance, advanced technology, and ease of maintenance.
* It is primarily used for the specialized cutting of aluminum door and window corner profile materials, and can also be utilized for cutting and processing curtain wall profiles and plastic profiles with increased thickness and length.
* The cutting tools employ imported hard alloy saw blades, ensuring high cutting speed, productivity, and machining precision.
* The machine's feed motion system employs linear motion bearings, resulting in low friction and high accuracy.
* The feeding mechanism utilizes an automatic feeding system, ensuring stability, reliability, and high efficiency.
* Equipped with an imported PLC programmable control system and numerical control device.
* Suitable for large-scale cutting production of aluminum doors and windows as well as plastic profiles.
* It boasts high automation, with pneumatic system control for clamping and blade movement, ensuring convenient, safe, and reliable operation with high productivity.

Specification

Model	LJMJ-CNC-450/ 500
Power	3.0kw
Motor Speed	3850r/min
Sawing Specifications	Φ450×Φ30mm×4.4mm/ Φ500×Φ30mm×4.4mm
Maximum Cutting Range	155x170mm
Cutting Angle	90°
Control System	CNC
After-sales Service Provided	Engineers available to service machinery overseas

The machine is simple to operate, reliable in performance, advanced in technology and easy to maintain. This machine is mainly used for cutting corner profiles on aluminum window doors. Also can be used for thickening and lengthening curtain wall profiles and plastic profiles. The cutting tool adopts imported linear motion bearing, which has high cutting speed, high productivity and high machining accuracy. The feed motion pair of this machine adopts linear motion bearing, which has small motion resistance and high precision. The feeding mechanism adopts an automatic feeding system, which is stable, reliable and efficient. Adopts PLC programmable control system and CNC Control. Suitable for mass cutting.
Detailed Photos

Factory Introduction

Shandong Weike CNC Machinery Co.,Ltd.is a well-known manufacturer specializing in the research, development, production and sales of aluminum doors, windows and curtain wall equipment in China. It's the most large-scale and industrialized production enterprise in the industry.
We have large production workshop and strong mechanical processing supporting capabilities, high-quality scientific research team and high-tech production team. We have strong research and development strength, perfect product system, and insists on independent innovation, improve products scientific and practical continuously. The company has several offices in China, forming a one-stop comprehensive service system integrating product development, production, sales and service.

Packing & Delivery

Professional package of mitre saw cutting machine: 1. Whole film packaging mitre saw cutting machine;
2. Anti-collision package edge;
3. Fumigation-free plywood wooden box and pallets with iron binding belt.

FAQ

Q:How to install and run the machine?
A: Our technician have installed the machine before shipping. For some small parts installation, we will send detail training video, user's manual along with the machine. 95% customers can learn by themselves.
Q:How can I do if the machine goes wrong?
A: If confronted with such problems, please contact us asap and do not try fix the machine by yourself or someone else. We will response within 24 hours as quick as we can to solve it for you.
Q:What customized services you provided?
A: WEIKE CNC is the true manufacturer, we have own factory, therefore we could supply full OEM and ODM service.
