C Type Automatic Rubber Vulcanization Press Machinery
Basic Info.
Model NO.
XLB-200T
Automatic Grade
Automatic
Power Source
Electric
Type
Rubber Vulcanizing Press
Name
Rubber Vulcanizing Press
Condition
New
Color
as Customers′ Requirements
Motor Power
5.5kw
Working Layers
1, 2, 4, as Customers′ Requirements
Man Power
1 Person for 1 Set of Rubber Vulcanizing Press
Outline Dimension
2920X1300X3880
Structure
Frame Type
Delivery Time
Within 30 Working Days After Receiving The Deposit
Payment Terms
T/T;L/C
Transport Package
Standard Export Packing
Specification
weight: about 5200kgs
Trademark
BOJIA
Origin
Qingdao, China
HS Code
8477800000
Production Capacity
50 Sets Per Month
Product Description
Jaw Type Rubber Vulcanizing Press MachineI. Features of rubber plate vulcanizing press
1. Fame structure
2.This press with PLC control, high production efficiency.
3. The presses heating method with steam heating or electrical heating we can as our clients required to design.
4. Press with automatic warning device, high safety and convenient.
5. The machines used for rubber vulcanization are known as rubber vulcanizing machines.
6. This rubber vulcanizing machine strengthens raw rubber by chemically treating it and make rubber harder and stronger.
This vulcanization machine is extremely useful for testing strength of rubber and find applications in numerous industries.
II. Technical parameter
| Type | XLB-DQ1200× 1200× 2 | XLB-DQ1300× 2000× 1 | XLB-Q1200× 2500× 1 | XLB-Q1500× 2000× 1 | XLB-Q2000× 3000× 1 | XLB-Q1400× 5700× 1 |
| Total Pressure(MN) | 315t | 560t | 750t | 1000t | 1800t | 2800t |
| Plate Size(mm) | 1200× 1200 | 1300× 2000 | 1200× 2500 | 1500× 2500 | 2000× 3000 | 1400× 5700 |
| Daylight (mm) | 200 | 400 | 400 | 400 | 400 | 400 |
| Layer NO. | 2 | 1 | 1 | 1 | 1 | 1 |
| Piston Stroke(mm) | 400 | 400 | 400 | 400 | 400 | 400 |
| Plate Unit Area Pressure | 22 | 21.5 | 25 | 33.5 | 30 | 35 |
| Main Motor Power(kw) | 3 | 8 | 9.5 | 11 | 26 | 43.5 |
| Overall Dimension(L× W× H) (mm) | 1685× 1320× 2450 | 2000× 1860× 2500 | 2560× 1700× 2780 | 2810× 1550× 3325 | 2900× 3200× 2860 | 2400× 5800× 3600 |
| Weight(kg) | 9500 | 17000 | 20000 | 24000 | 66000 | 110000 |
III. Our machine list
Our company professional manufacture rubber vulcanizing press (frame type,four column type,lab press and so on), rubber mixing mill, batch off cooler, rubber extruder, rubber strip making machine and tire recycling equipment.
