Vertical Drilling Machine Z5032c/1 Z5045c/1 Z5040c/1
| US$2,500.00-4,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
Z5032C/1 Z5045C/1 Z5040C/1
Structure
Vertical Drilling Machine
Layout
Vertical
Controlling Mode
Manual
Number of Shaft
Manual
Hole Diameter
Manual
Automatic Grade
Manual
Precision
Precision
Certification
CE, ISO 9001
Condition
New
Max. Driiling Capacity
32mm
Max. Taping Capacity
Mt3
Max.Spindel Travel
130mm
Spindel Speed
80-1250rpm
Motor Power
0.75kw
Transport Package
Plywood Case
Specification
Cast Iron
Trademark
HOYONG-TRD
Origin
Shandong, China
HS Code
845929000
Production Capacity
300
Product Description
Vertical Drilling Machine Z5032C/1 Z5045C/1 Z5040C/1
Drilling, milling and tapping
Head swivels 360 horizontally
Headstock and Worktable up & down perpendicularly
Super high column
Precision micro feed
Positive spindel lock
Distinct auto device for releasing tools, operate easily
Geared drive, lower noise
Product main technical Specifications:
| Specifications | Z5032C/1 | Z5040C/1 | Z5045C/1 |
| Max. Drilling dia. | 32mm | 40mm | 45mm |
| Spindle taper | M.T.3 or R8 | M.T.4 | M.T.4 |
| Spindle travel | 130mm | 130mm | 130mm |
| Step of speed | 6 | 6 | 6 |
| Range of spindle speed 50Hz | 80-1250 r.p.m | 80-1250 r.p.m | 80-1250 r.p.m |
| 60Hz | 95-1500 r.p.m | 95-1500 r.p.m | 95-1500 r.p.m |
| Step of spindle auto-feeding | 6 | 6 | 6 |
| Range of spindle auto-feeding amount | 0.06-0.30mm/r | 0.06-0.30mm/r | 0.06-0.30mm/r |
| Min.distance from spindle axis to column | 290mm | 290mm | 290mm |
| Max.distance from spindle nose to worktable | 700mm | 700mm | 700mm |
| Max.distance from spindle nose to stand table | 1125mm | 1125mm | 1125mm |
| Max.travel of headstock | 250mm | 250mm | 250mm |
| Swivel angle of headstock(horizontal) | 360° | 360° | 360° |
| Max.travel of worktable bracket | 600mm | 600mm | 600mm |
| Table Size | 730×210mm | 730×210mm | 730×210mm |
| Size of stand worktable of avaliability | 417×416mm | 417×416mm | 417×416mm |
| Forward and afterward travel of worktable | 205mm | 205mm | 205mm |
| Left anf right travle of worktable | 500mm | 500mm | 500mm |
| Vertical travel of worktable | 570mm | 570mm | 570mm |
| Motor Power | 0.75kw | 1.1kw | 1.5kw |
| speed of motor | 1400rpm | 1400rpm | 1400rpm |
| Coolant pump power | 0.04kw | 0.04kw | 0.04kw |
| Net weight/Gross weight | 437/500kg | 442/502kg | 443/505kg |
| Packing size | 1850x750x1000mm | 1850x750x1000mm | 1850x750x1000mm |
