5 Liter Tri-Shaft Planetary Vacuum Mixer with Vacuum Pump and Water Chiller
| US$6,700.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
CY-MSK-SFM-9
Application Area
Metallurgy&Mineral
Certification
CE, TUV
Condition
New
Stirring Type
Spiral
Working
High Speed Mixer
Lift Motor
370W
Stirring Speed
0-112rpm
Control Panel
Digital Touch Screen
Main Shaft Speed
0-70 Rpm
Warranty
12 Months
Mixer Type
Planetary Mixer
Layout Type
Verticle
Mixing Drum Shape
Disc
Operating type
Continuous Operating
Transport Package
Wooden Box
Specification
5L
Trademark
CY
Origin
Zhengzhou, China
HS Code
85141090
Production Capacity
310 Sets Per Month
Product Description
5 liter Tri-Shaft Planetary Vacuum Mixer with Vacuum Pump and Water chiller - MSK-SFM-9Introduction
MSK-SFM-9 is a CE Certified Vacuum Planetary Mixer with 5 liter containers and complete accessories for immediate use. The vacuum mixer produces multi-movements during stirring, including, revolution and rotation, double stirring shafts, single scattered shaft & scraping the walls to make slurry gas-bubble free and with extreme uniformity under vacuum.
A temperature-controlled water circulator is included to make container working at temperature range from 50ºC to 35ºC directly and water cold stainless steel tank can promise high efficiency in mixing. SFM-9 is excellent for preparing LiCoO3, LiFePO4, phosphors and ceramic slurry with excellent results in dispersion and uniformity.
Specification
| Power Supply | Single phase, AC 208 - 240V 50/60Hz, single phase Total power: 4kW 220V AC Power plug is not included. |
| Revolution Speed | Main shaft speed: 0 - 70 rpm Stirring speed: 0 - 112 rpm, motor: 2.2kW Dispersing speed: 0 - 6100 rpm, motor: 1.5kW |
| Vacuum | The vacuum pump: 0.37kW built in The vacuum degree: <= -0.098MPa |
| Lift Motor | Lifting Motor is built in ( 370W) |
| Bucket | Dimensions: Dia.240mm * H.180mm Capacity: 5 Liter Water cooling jacket Temperature monitor and over-temperature alarm |
| Beater | Tolerance of beater and bottom: 2-4 mm Tolerance of beater and bucker wall: 2-5mm Tolerance of two beaters: 3-8mm Made of SS 304 |
| Water Recirculating Chiller | One Digital Temperature Controlled Recirculating Water Chiller with 6 Liters Tank, 16L / min Flow - EQ-KJ5000-220 included |
Connected Accessories & Fittings | DN50 feed hole Three-piece type ball valve outlet Two DN50 sight glasses One G1/2" vacuum connector with vacuum pump One G1/2" air outlet One vacuum meter 12mm O.D. water inlet and outlet fittings |
| Control Panel | Digital Touch Screen for efficient adjustments |
| Compliance | CE Certified |
| Warranty | One year limited warranty with lifetime technical support |
| Overall Dimension | 1000mm(L) x 800mm(W) x 1930mm(H) |
| Net Weight | 300 kg (660 lbs) |
Zhengzhou CY Scientific Instrument Co., Ltd is mainly engaged in the research and development, design, manufacturing and sales of equipment used in scientific researches. Independence and innovation is the company's tenet.Our main products include: tube furnace, muffle furnace, plasma cleaner, vacuum furnace, atmosphere furnace,CVD system and customized
lab equipment.Welcome you come to visit us.
