CETC AIS MOB VSA8 PLB

CETC AIS MOB VSA8 PLB

Product Description

Product Description
oduction:Model Number:VSA8
Application Area:VSA8 is specially developed for crew’s daily working. It can also be used in the person working under dangerous environment. VSA8 is with 8year’s free maintenance, no need to pay communication fee and extremely low cost.
Certificate:It is complied with the standard of IEC61097-14, ITU-R M.1371.
Specification1. GENERAL:
Battery: lithium battery,8 years’ life
Performance time:>24h@-20℃/ 0.5min~5min transmission signal/optional
Antenna: vertical monopole?
programming interface:Two-way infrared
Compass: electronic formula
LCD: 128*64 lattices
Activation way: manual/By water
Agreement support: MSG1, MSG14
Water-proof properties: 5m/10 mins
Size: 90mm*49mm*30mm
Weight: 116g
Working Temp.:-20℃- 55℃
Storage Temp.:-40℃- 70℃
2.AIS Transmitter
Output frequency: 161.975 MHz, 162.025 MHz
Output power:2W(33dBm)±1.5dB
Data rate: 9600bps
Modulation bandwidth: 25 KHz
Modulation mode: GMSK, FM
Repeat cycle: 1 min
Action distance: 7km (Typical)
3.Satellite positioning receiver (GNSS)
Satellite positioning system: GPS, Beidou satellite (compass 2)
Receiving channel: 56 channels, L1+B1
Receiving Antenna: built-in ceramic plate
Receiving Sensitivity:-165dBm
Positional error: 2.5m
