Innovative Corn Harvester with Wheeled Structure for Optimal Performance

Product Description

Company Profile
Ruiyuan Holdings Group, majestically nestled in Qingdao's West Coast New District, proudly ranks among the top 100 private enterprises in Shandong Province. With a staggering registered capital of 800 million yuan and total assets surpassing 20 billion yuan, we are fortified by a dedicated workforce of over 9,200 professionals. Our diversified portfolio spans engineering construction, cutting-edge manufacturing, energy and power, healthcare, and port logistics. Our business footprint extends beyond domestic provinces and cities, reaching the vibrant economies of the Asia-Pacific, the Middle East, Pan-Russia, Europe, Africa, North America, and Latin America.
Ruiyuan Holdings Group International Trade Co., Ltd. leverages the formidable strengths of Ruiyuan Group's diverse industrial sectors and its own state-of-the-art factories to deliver comprehensive and resilient supply chain resources and top-tier services to our global clientele.
With eight years of rigorous market verification, the Ruiyuan Dima brand has firmly established a prestigious image of "high-end and reliable" in the minds of our discerning users. Our brand is the epitome of high-end allure, eagerly sought after in our target markets. Recognized by esteemed industry associations, we have proudly received numerous accolades, including the Product Technology Innovation Award, the Product Application Contribution Award, the esteemed TOP50 Market Leadership Award, and the Technological Progress Award.
Looking to the future, we remain steadfast in our "green, science and technology, a better future" business philosophy. Our ambition is to establish the company as a domestic beacon of high-end agricultural equipment manufacturing, striving to be a leading force in the renaissance of China's agricultural equipment industry.
Our company passionately engages in the R&D, production, and sale of multifunctional self-propelled combine harvesters and high-horsepower tractors. As a pivotal member of the China Agricultural Machinery Industry Association, the China Agricultural Machinery Circulation Association, and the China Agricultural Mechanisation Association, we have achieved ISO9001 quality management system certification, underscoring our commitment to excellence.
Product Description

Model name	4YZL-6 (shenlong)self-propelled corn grain combine harvester
Structural Style	Wheeled,Picking ears,Direct harvesting of grains
Mating engine type specification	YCA07P260-T400(National IV)
Mating engine power rating (kW)	191
Mating engine rated speed (r/min)	2200
Overall dimensions (L×W×H)	10500×4200×3900
Whole machine weight (kg)	12000
Row spacing (mm)	650
Working width (mm)	3970
Minimum Ground Clearance (mm)	390
Operating speed (km/h)	1.05-7
Operating productivity (km²/h)	1.1-1.5

Model name	4YZ-6D2 (ruilong)self-propelled corn grain combine harvester
Structural Style	Wheeled,Picking ears,Skin peeling,Straw recycling
Mating engine type specification	YCA07P210-T300(National IV)
Mating engine power rating (kW)	154
Mating engine rated speed (r/min)	2200
Overall dimensions (L×W×H)	9900×3500×3800
Whole machine weight (kg)	11300
Row spacing (mm)	300
Working width (mm)	3440
Minimum Ground Clearance (mm)	360
Operating speed (km/h)	1.05-7
Operating productivity (km²/h)	0.5-1.3

Model name	4YZL-6(menglang) self-propelled corn grain combine harvester
Structural Style	Wheeled,Stripping,Peeling,Straw recycling
Mating engine type specification	YCA07P260-T400(National IV)
Mating engine power rating (kW)	191
Mating engine rated speed (r/min)	2200
Overall dimensions (L×W×H)	8300×2700×3900
Whole machine weight (kg)	10000
Row spacing (mm)	600
Working width (mm)	2400
Minimum Ground Clearance (mm)	300
Operating speed (km/h)	1.05-7
Operating productivity (km²/h)	0.4-0.8

Model name	4QZ-4500(muwang)self-propelled forage harveste
Structural Style	Self-propelled Disc cutter
Mating engine type specification	YCK09P560-T400(National IV)
Mating engine power rating (kW)	480
Mating engine rated speed (r/min)	2200
Overall dimensions (L×W×H)	6800×3640×5600
Whole machine weight (kg)	10500
Row spacing (mm)	/
Working width (mm)	2430
Minimum Ground Clearance (mm)	180
Operating speed (km/h)	1.05-25
Operating productivity (km²/h)	1.4-2.8

Detailed Photos
Our Advantages
About Us
Corporate Team & Events
FAQ

Q: What information is essential for prompt and exact evaluation?A: Exact compression media, working pressure, required loading volume, acceptable manufacture/inspection standard, and any special requirements.Q: How do you do quality control in your factory?A: Quality is the first priority, the products are only allowed to leave the factory after 100% qualified by inspection, we will check again before shipment to ensure the quality, we also provide customers with up to 18 months of warranty!Q: Can you design according to specific client parameters?A: Yes, we can design exactly as per clients' parameters to satisfy their local environment and different needs.
