USB 3.1 Extender Over CAT6

Product Description

Overview The caratar USB is the world's first USB 3.1 extender allowing users to extend USB 3.1 Gen 1 (5Gbps) device types as well as USB 2.0 and 1.1 devices across a point-to-point connection up to 100m over a single CAT 6a/7 cable. Applications include extending USB 3 conferencing cameras and audio devices for boardrooms and conference rooms. The extension series has been successfully tested with most major USB 3.1 conferencing cameras in conjunction with major UC conferencing applications (Zoom, Teams, Skype).
This 4-port USB 3.1 extender supports data rates at up to 5Gbps and is plug and play - no software drivers required - for all major operating systems: Windows®, macOS™, Linux® and Chrome OS™.
Additionally, this ExtremeUSB-C™ based USB 3.1 extender system is FCC/CE Class B certified and, being backward compatible, is ideal for use with all USB peripherals in addition to USB 3.1 conference cameras including: flash drives, hard drives, keyboards, mice, interactive white boards, touchscreens, audio devices, and other USB 3, 2 and 1 devices.

Features USB 3.1 Gen 1 data rate up to 5Gbps Integrated 4-port USB 3.1 hub supporting all USB 3.1, 2.0, 1.1 devices simultaneously at full bandwidth; although if Isochronous support is required Up to 1.2A (6W) per USB port 100/1000Mbps Ethernet channel; LAN pass-through Single cable, CAT 6a/7 up to 100m Point-to-point connection FCC and CE (Class B) compliance Two year warranty suite of features: Transparent USB extension supporting USB 3, 2 and 1 True plug and play; no software drivers required Works with all major operating systems: Windows®, macOS™, Linux® and Chrome OS™ Specifications RANGE
Direct connect up to 100m (328 ft) over CAT 6a/7 cable SPEEDS
USB 3.1: up to 5Gbps USB 2.0: up to 480Mbps USB 1.1: up to 12Mbps LEX (Local Extender)
1x USB 3.1 Gen 1 Type B Receptacle 1x RJ45 Ethernet 100/1000 Port 1x RJ45 Ethernet Link Port 24V 1A DC Locking Jack Enclosure Material: Silver anodized aluminum Dimensions: 137.3mm x 232.1mm x 33.0mm (5.4″ x 9.1″ x 1.3″) 920g (2.03 lbs.) Mounting: 4 surface mounting holes or optional mounting kit available REX (Remote Extender)
4x USB 3.1 Gen 1 Type A Receptacles 1x RJ45 Ethernet 100/1000 Port 1x RJ45 Ethernet Link Port 24V 2.71A DC Locking Jack Available Current: up to 1.2A (6W) per USB port Enclosure Material: Silver anodized aluminum Dimensions: 137.3mm x 232.1mm x 33.0mm (5.4″ x 9.1″ x 1.3″) 990g (2.18 lbs.) Mounting: 4 surface mounting holes or optional mounting kit available ENVIRONMENTAL
Operating Temperature: 0C to 50C (32F to 122F) Storage Temperature: -20C to 70C (-4F to 158F) Operating Humidity: 20% to 80% relative humidity, non-condensing Storage Humidity: 10% to 90% relative humidity, non-condensing COMPLIANCE
EMC: FCC (Class B), CE (Class B) Environmental: RoHS2/3, REACH, Conflict Minerals SUPPORT
Warranty: 2-year In the Box The extender system includes:
Local Extender (LEX) Remote Extender (REX) USB 3.1 Gen 1 Cable LEX 24V DC 1A International Power Adapter REX 24V DC 2.71A International Power Adapter 2 x Country Specific Power Cords Quick Start Guide Two year warranty Applications Remote Storage Security & Monitoring Video Matrix Systems Conferencing Cameras Medical Device Connectivity USB 3.1 Fiber Extender Introducing the USB 3.1 Extender Over CAT6, a cutting-edge solution designed to revolutionize your cross-border e-commerce experience. With a perfect blend of industry expertise and marketing know-how, this product description aims to captivate your attention and provide you with specific details about this remarkable device.
The USB 3.1 Extender Over CAT6 is a game-changer in the world of cross-border e-commerce platforms. It allows you to extend your USB 3.1 connection over CAT6 cables, ensuring seamless and uninterrupted data transfer. With this innovative device, you can now effortlessly connect USB devices to your computer or laptop, even when they are located at a considerable distance.
Featuring the latest USB 3.1 technology, this extender guarantees lightning-fast data transfer speeds of up to 10 Gbps. Say goodbye to frustratingly slow connections and hello to a world of efficiency and productivity. Whether you are a professional working on complex projects or a gaming enthusiast seeking lag-free gameplay, this extender will exceed your expectations.
The USB 3.1 Extender Over CAT6 is incredibly easy to set up and use. Simply connect the transmitter to your computer and the receiver to your USB device, and you're good to go. No complicated installations or technical expertise required. Its plug-and-play functionality ensures a hassle-free experience, allowing you to focus on what truly matters.
This extender is compatible with a wide range of USB devices, including printers, scanners, cameras, and external hard drives. It supports various operating systems, including Windows, Mac, and Linux, making it a versatile solution for all your cross-border e-commerce needs.
In conclusion, the USB 3.1 Extender Over CAT6 is a must-have product for anyone seeking to enhance their cross-border e-commerce experience. With its exceptional performance, easy setup, and broad compatibility, it is the perfect solution for professionals and enthusiasts alike. Don't miss out on this opportunity to take your productivity to new heights. Order your USB 3.1 Extender Over CAT6 today and unlock a world of possibilities.
