New Construction Machinery Zoomlion Zcc2600 260 Tons Crawler Crane for Sale

New Construction Machinery Zoomlion Zcc2600 260 Tons Crawler Crane for Sale

US$150,000.00-280,000.00 1 unit (MOQ)

Basic Info.

Model NO.
ZCC2600
Max. Rated Lifting Capacity
260 T
Heavy Boom Length
20-83 M
Light Boom Length
86~95 M
Jib Length
12-30 M
Tower Attachment Length
21-60 M
Gradeability
30%
Size
10.36*3.4*3.0 M
Engine Power
227 Kw
Max Mass of Single Unit
32 T
Transport Package
Nude Package
Specification
ISO, CE, GOST
Trademark
ORIEMAC
Origin
Jiangsu, China(Mainland)
HS Code
84295212
Production Capacity
800PCS/Month

Product Description

New Construction Machinery ZOOMLION ZCC2600 260 Tons Crawler Crane for Sale
EFFICIENT, QUICK AND SAFETY
The mechanism operating speed up 20%, and the speed of each mechanism don't slow down while operating 2 functions simultaneously;
Time of erecting the whole crane is less than 6 hours;
Omni-directional real-time LMI and monitoring system, to ensure safety operation.

CONVENIENT, COMFORTABLE AND INTELLIGENCE
The max. Single transport weight is 30.5t, transport width is 3m;
Omni-directional vehicle information platform, real time monitoring equipment operation,
The IOT intelligent interaction system make the mobile service come true.
Full view cabin, buttons and switches are all within reach, all-around air conditioner form a comfortable operating space.

Item Unit Value Remarks
Maximum lifting capacity × radius t × m 260 × 5
Deadweight of crane with basic boom t 210
Length of main boom S-boom length m 20-83
SL-boom length m 86-95
F-jib length m 12-30
Max.lifting capacity on fixed jib t 34
F-jib angle . 10,30
Max. length of heavy duty boom with fixed jib m 77+30
W-jib Length m 21-60
Max. lifting capacity on luffing jib t 73.5
S-boom angle( for SW boom configuration) . 65-85
Max. length of heavy duty boom with luffing jib m 62+60
Single rope speed of winches Hoisting winch 1 m/min 130 on the 6th rope layer
Hosting winch 2 m/min 120 on the 6th rope layer
Main boom derricking winch m/min 80× 2 on the 6th rope layer
Slewing speed rpm 0-1.2
Traveling speed km/h 0-1.0
Max.gradeability % 30
Ground pressure MPa 0.115
Transport weight of max.single unit t 32 Excluding hoisting winches,titling-back support of main boom.A-frame and derricking mechanism
Rear counterweight t 83.7
Central counteweight t 32
Engine Manufacturer US Cummins
Rated power/rotational speed Kw/rpm 227/2000
Max. output torque/rotational speed Nm/rpm 1505/1400
Emission standard U.S.EPA Tier 3 and EU Stage III A
