Factory Directly Sale Stainless Steel Milk Cooler Dispenser

Product Description

Related Products

Product Parameter

Model	Working volume (L)	Cooling Capacity (W)	Dimension (LxMxH) (mm)	Motor power (kw)	Agitator speed (r/min)
JTCV-500	500	3500	2200*1350*1150	1.5	36/24
JTCV-1000	1000	6900	2750*1150*1500	3	36/24
JTCV-1500	1500	10000	3000*1350*1550	4	36/24
JTCV-2000	2000	13000	3200*1500*1600	5	36/24
JTCV-3000	3000	17800	3500*1650*1700	6.5	36/24
JTCV-5000	5000	34000	4000*1950*2000	13	36/24
JTCV-6000	6000	34000	4200*2200*2100	13	36/24
JTCV-8000	8000	42000	4800*2400*2400	18	36/24
JTCV-10000	10000	65000	5000*2600*2500	24	36/24
Other sizes can be custom made per clients requirement!

Main Features: The tank is insulated to maintain the temperature and is provided with an agitator for uniform distribution and cooling of milk. Efficient evaporator ensures quick and trouble-free cooling and space-saving installation. A high cooling capacity is guaranteed and freezing is prevented for small amounts of milk. The tank is built from polished stainless steel for durability and ease of cleaning, meet or exceed world standards, including 3-A Sanitary requirements.

Product Display
Key Components

High Quality and Nicely Built fresh milk cooling tank for Your Trust and Honored Choice!




01, Glass Manhole

The high pressure sight glass manhole is a way for raw material loading and deep cleaning. The operator can see the mixing process inside the boiler clearly. So that all reactions changes inside the tank can be monitored closely and timely. This manole can be made in stainless steel with a sight glass union too per clients requirement. But all these manles should bear high pressure in order to avoid any air leaks during the production process.






02, Ex-proof Electric Motor
The Ex-proof elctric motor is connected with a gear box to drive the mixing blade to stir the raw materials inside the tank. The raw materials can be liquid, paste or sometimes powder. The Ex-proof electric motor is very important for some specific industries, such as alcohol distillation and chemicals.







03, Mixing Blade
Actually, there are many different kinds of mixing blades, such as paddle mixer, anchor mixer, magnetic mixer, spiral ribbon mixer etc.. The customers can choose the most suitable one per the requirement of application.






04, Liquidmeter
The liquidmeter is usually required if you are going to proceed the liquid materials. You can check and closely monitor the latest liquid level of the material inside the tank during the production process. There are common sight glass liquidmeter, magnetic flap level gauge and so on.
05, Control Panel
The operator can control the raw material loading, heating, mixing and transfer easily by the control panel. The whole process can be done semi-automatic and fully automatic per clients requirement.
Production Process
Company Profile
FAQ
Q: Are you a manufacturer or trading company? A: Junteng is leading manufacturer based in Wenzhou, China. Q: Which kind of product can you make? A: We are producing and supplying distillery equipment, dairy equipment, crafts beer equipment, tanks and sanitary components.
Q: Can you make the products per our requirement? A: Yes, Junteng has strong R&D team that can provide you customized solution and products.
Q: Will you charge us for drafting drawing and designing? A: No, we provide free engineering and designing services for our customer if that is necessary.
Q: What is the warranty of your products? A: The standard warranty is 1 year for our products.
Q: Can you provide service and instruction for installation after delivery? A: Yes, we can provide you free instruction and support online. We can also send engineer to your factory for onsite instruction. But you need to pay the travel expense.
Q: Can we become your local distributor? A: Yes, we are working with many distributors all over the world. We'll be glad to discuss with you for the details if you have interest.
Q: What is your required MOQ? A: The MOQ is 1pc for the stock products. The MOQ of custom made product should be per discussion.
