Vacuum Hopper Hopper Automatic Extrusion Blowing Blow Molding Moulding Machine
| US$3,700.00-4,000.00 | 1 pc (MOQ) |
Basic Info.
Raw Material
PET
Making Method of Parison
Extrusion-Blow Molding
Automation
Automatic
Computerized
Computerized
Certification
CE
Capacity
1450kg/Hr
Usage
Feefing&Converying
Function
Muti Station Hopper Loader
Power(W)
5.5kw
Voltage
3pH400V50Hz
Motor
Siemens Brand
Weight
180kg
Transport Package
Wood
Specification
1780*760*600mm
Trademark
Sanzhong
Origin
Guangdong
HS Code
84778000
Production Capacity
2000PC\Year
Product Description
Scope of application: "One-to-More" Separate hopper loaders are designed and developed on the basis of original separate-vacuum Hopper Loaders. They feature more functions, easy to operate, and convenient to install. This model, equipped with a high pressure blower and more hoppers, is applicable to more dehumidifying and drying machines (dehumidifying dryer "CDD" or one gravimetric blenders "CGB" to process plastic materials. Besides that , it can also realize the one-to-more way of conveying materials to different moulding machines or hoppers to greatly lower the cost.
Feature:
| 1.One-to-More" hopper loader can greatly lower the cost. |
| 2.The dust collection chamber features a cyclone separator and a dust collective bin to effectively reduce the load of the filter. |
| 3.Separate hopper receivers are designed in classy standard style, made by stainless steel, and bringing no contamination to materials. |
| 4.One-piece PLC controller, the operation is simple, reliable performance |
| 5.Motor protection device. |
| 6.Standard audible and visual alarm device configuration. |
| 7.When conveying materials of tiny impurity is more, or contain recycling materials, host optional store pressure tank automatic cleaning device. |
| Note: 1) Power supply:30PH400V50Hz 2) Test condition of conveying capacity: Plastic material of bulk density 0.65, dia.3 ~ 5 mm, vertical conveying height: 4m, horizontal conveying distance: 5m. 3) CHR stands for vacuum hopper, CHR-E stands for photo-sensor hopper. 4) Optional filter cleaning device (model denotes "C") and air accumulator (model denotes "A") available for automatic filter cleaning, (for 3.5HP-G up) 5. We reserve the right to change specifications without prior notice. |
Specifications:
| Main unit | Hopper Receivers | Conveying Pipe Dia. (inch) | Conveying Capacity (kg/hr) | ||||||
| Model | Motor Power (kW) | Size (mm) | Weight (kg) | Model | Volume (L) | Size (mm) | Weight (kg) | ||
| CUL-1HP-G | 1.1 | 860 x 360 x 420 | 50 | CHR-6 | 6 | 420x285x360 | 6 | 1.5" | 300 |
| CHR-6-E | 600x275x360 | 8 | |||||||
| CUL-2HP-G | 1.6 | 860x360x420 | 54 | CHR-12 | 12 | 470 x 315 x 400 | 7 | 1.5" | 500 |
| CHR-12-E | 700 x 315 x 400 | 12 | |||||||
| CUL-3.5HP-G | 2.2 | 1340x515x500 | 73 | CHR-24 | 24 | 690 x 315 x 400 | 9 | 2" | 750 |
| CHR-24-E | 1120 x 360 x 400 | 13 | |||||||
| CUL-5HP-G | 4 | 1340x515x500 | 74 | CHR-24 | 24 | 690 x 315 x 400 | 9 | 2" | 1000 |
| CHR-24-E | 1120x360x400 | 13 | |||||||
| CUL-7.5HP-G | 5.5 | 1780 x 660 x 600 | 156 | CHR-36 | 36 | 930 x 315 x 400 | 11 | 2" | 1200 |
| CUL-10HP-G | 7.5 | 1780 x 660 x 600 | 160 | CHR-36 | 36 | 930x315x400 | 11 | 2" | 1600 |
| CUL-15HP-G | 12.5 | 1940x700x800 | 226 | CHR-48 | 48 | 975x350x475 | 15 | 2.5" | 2000 |
