4000L Magnetic Coupling Stirring Agitator Hydrogenation Batch Reactor
| US$52,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
GSHA
Type
Reaction Kettle
Material
Stainless Steel
Capacity
>1000L
Structure
Jacket and Coil Tube
Pressure
Positive
Agitator Model
Combined Agitator
Heating
Outside (Inside) Coil Heating
Heat Transfer Structure
Combined
Automatic Grade
Automatic
Condition
New
Power
18.5kw
Design Pressure
6.4MPa
Max Work Pressure
6.5MPa
Weight
8202
Oversea Branch
California, Us
Transport Package
Wood Box
Specification
4000L
Trademark
LUHAO
Origin
China
HS Code
84198990
Product Description
Vessel Capacity m³: 6.4 Material: S31603+Q345R Design pressure MPa: 6.4 Design temperature ºC: 230 Work pressure MPa: 5.0 Work temperature ºC: 200 Medium: Hydrogen, catalyst Working life: 10 years Jacket Volumn m³: 0.6 Material: Q245R Design pressure MPa: 0.7 Design temperature ºC: 170 Work pressure MPa: 0.6 Work temperature ºC: 20-165 Medium: steam/ cooling water Heat exchange area m2: 11.9 Coil tube Volumn m³: 0.09 Material: S31603 Design pressure MPa: 0.6 Design temperature ºC: 230 Work pressure MPa: 0.5 Work temperature ºC: 200 Medium: heat-transfer oil Heat exchange area m2: 10.4 Total weight Kg: 8202 For confidential reason, the drawing is in low definition. Please contact us for more information.| MODEL | FCHA1000-2000L | FCHA3000-5000L | FCHA6000-8000L | FCHA10000-15000L | FCHA15000-25000L |
| CAPACITY | 1000-2000L | 3000-5000L | 6000-8000L | 10000-1 5000L | 15000-25000L |
| WORK PRESSURE MPa | -0.1-10.0 | -0.1-10.0 | -0.1-10.0 | -0.1-10.0 | -0.1 -8.0 |
| WORK TEMPERATURE C° | -15-320 | -15-320 | -15-320 | -15-320 | -15-320 |
| rpm | 0-320 | 0-320 | 0-320 | 0-320 | 0-320 |
| DC motor power W | 3.0-11.0 | 11.0-22.0 | 15-37.0 | 22.0-55.0 | 37.0-75.0 |
| Main materials | 09MnNiDR/16MnDR (low-temperature steel), 15CrMoR (high-temperature steel), stainless steel S30408/S32168/S31603, S39042, titanium material, duplex steel, shackle material, Hastelloy alloy, zirconium material, Monel, and other materials used for explosive composite plates. | ||||
| Heating form | Jacket thermal oil, jacket steam, outer half pipe, inner coil pipe; Electric heating/flue gas heating (435ºC). | ||||
| Mixing form | Disc turbine type, asymmetric turbine type, three blade impeller type, disc inclined blade, four wide blade, propulsion type, impeller type, anchor type, frame type, screw belt type, etc. | ||||
| Shaft sealing form | Magnetic coupling drive with static sealing, zero leakage, long service life, simple installation, safe and environmentally friendly. | ||||
| Remarks | Other special requirements, touch screen intelligent control, program control, and connection to DCS systems shall be designed, manufactured, and configured according to user needs. | ||||
| LUHAO Chemical Machinery Co. Ltd | |||||
| Pressure Vessel Design Information Collection Table | |||||
| Vessel | Jacket (Coil) | ||||
| Work Medium | Name | ||||
| Components | |||||
| Density (Kg/m³) | |||||
| Characteristics | |||||
| Viscosity (cP) | |||||
| Flow Velocity(m³/h) | |||||
| Design pressure (Mpa) | |||||
| Work pressure (Mpa) | |||||
| Design temperature(ºC) | |||||
| Work temperature (ºC) | |||||
| Wall temperature (ºC) | |||||
| Diamter (mm) | |||||
| Length (mm) | |||||
| Capacity(m³) | |||||
| Effective capacity (m³) | |||||
| Corrosion allowance (mm) | |||||
| Corrosion speed (mm/year) | |||||
| Recommended Materials | |||||
| Lowest value of average monthly temperature(ºC) | |||||
| Site location | |||||
| Installation condition | Indoor or Outdoor | ||||
| Catalyst Volume(m³) | |||||
| Catalyst Density(Kg/m³) | |||||
| Heat Transfer Area(m2) | |||||
| Coil Specification | |||||
| Basic Wind Pressure(Mpa) | |||||
| Seismic Basic Intensity | |||||
| Ambient Temperature(ºC) | |||||
| Site Type | |||||
| Operating Mode | |||||
| Insulation Materials | Name | ||||
| Thickness | |||||
| Density (Kg/m³) | |||||
| Seal Requirements | |||||
| Liquid Level Gauge | |||||
| Emergency Cut-off | |||||
| Static Electricity Removal | |||||
| Anti Eddy Current Requirement for Liquid Outlet | |||||
| Installation and Mantainance Requirements | |||||
| Expected Useful Life (years) | |||||
| Safety accessories | Vessel | Jacket (Coil) | |||
| Location | |||||
| Type | |||||
| Specification | |||||
| Quantity | |||||
| Set pressure(Mpa) | |||||
| Burst disc | |||||
| Burst pressure(Mpa) | |||||
| Safety discharge(kg/h) | |||||
| Agitator | Type | ||||
| Impeller Diameter(mm) | |||||
| Speed(r/min) | |||||
| Motor | Model | ||||
| Power(kw) | |||||
| Explosion Proof Grade | |||||
| Speed reducer | |||||
