10cbm 15cbm Mobile Gas Filling Tank Truck LPG Bobtail Truck

Product Description

10cbm 15cbm Mobile Gas Filling Tank Truck LPG Bobtail Truck
Condition	New condition/LHD
Chassis	Brand		Dongfeng
	Curb weight(kg)		7295
	G.V.W.(kg)		15000
	Wheelbase(mm)		4700
	Dimensions(mm)		9000×2462×3250
	Overhang (front/rear) (mm)		1205/2495
	Approach/Departure angle(°)		30/32
	Max. driving speed(km/h)		90
	Tire	Quantity	6pcs with one spare tire
		Specification	10.00-20
Clutch	Reinforced diaphragm clutch
Gear box	6 Forwards & 1 reverses
Engine	Model		Commins, B190 33
	Fuel type		diesel
	Displacement(ml)		5900
	Power(kw)		140
	Horsepower(HP)		190
	Cylinder number		6
	Emission standard		Euro 3
Brakes	Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake
Cab	3 Passenger Allowed, with A/C
Steering Gear	Power steering, hydraulic steering with power assistance
Tank Parameter
Tank material	Carbon Steel Q345R
Loading capacity(cbm)	15cbm(15000 liters)
Tank shape	Double ellipse
Thickness of Shell(mm)	6
Thickness of End plate(mm)	10
Filling Medium	Liquefied Petroleum Gas ( Propane)
Corrosion Allowance(mm)	1
Filling ratio	0.42
Design pressure(Mpa)	1.61Mpa
Medium Density	420kg/cbm
Safety Accessory Parts: Safety valve, Cut-off Valve, thermometer, liquid level gauge, pressure gauge

China brand LPG Pump Specification
	Pump Brand	China local famous brand
	Medium	Liquid petroleum gas
	Material	Nodular Cast Iron
	Liquid Delivery Value	5.2m³/h~15m³/h
	Inlet & Outlet Flange	2"NPT / 2" NPT

Our advantage:
· Competitive Price and Excellent Quality,
· More than 11 years' experience as a manufacturer,
· CCC,ISO,BV certification,
· Perfect after-sale service,
· Customized products available with us,
· Export covering More than 50 countries and regions ,
· Annual production value topped 1500,000,000 RMB (240,000,000 US dollars) per year.
Introduction

CLW Heavy Industry Co.,Ltd is the branch company of Chengli Special Automobile Co.,Ltd.Chengli Special Automobile Co., Ltd, as the professional manufacturer in the special vehicle circle, has developed into the biggest professional special vehicle manufacturer of central China starting from scratch since 2004.
Chengli Special Automobile Co., Ltd Factory Supply:
a.special truck manufacturers in Suizhou city,HuBei province, china,
b.more than 300 kinds of special truck for your needing.such as garbage truck,LPG truck ,fuel truck , water truck ,high platform truck , dump truck , concrete mixer truck ,truck mounted crane ,chemical tank truck , fire fighting truck ,bulk cement truck ,flat bed trailers , low bed trailer , cargo trailer tipper trailer ,fuel trailer ,LPG trailer and more
c.Nearly 15 years experience in produce truck and truck parts field.
d. export turnover has reached 25million dollars and our products have been sold to more than 50 countries, including Africa ,Europe,Southeast Asia, Middle East, North Asia and so on.
Owing to our rich industrial experience,we are offering a wide range of products to the customers, such as LPG tank, fuel tank, water truck, refrigerator truck,garbage truck and so on. We ensure to deliver those products at industry leading price range to meet the financial constraints of our clients.
