Module spare parts SSA-G1018-0652

Product Details

Product Description

Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

SSA-G1018-0652

DeltaV SIS Hardware The DeltaV SIS process safety system consists of the following hardware: „ Redundant Logic Solvers (SLS 1508) and termination blocks „ SISNet Repeaters (see separate product data sheet) „ Carrier extender cables „ Local peer bus extender cables „ Right 1-wide carrier with termination Logic Solvers (SLS 1508) contain the logic-solving capability and provide an interface to 16 I/O channels that can be configured as Discrete Input, Discrete Output, Analog Input (HART) and HART two-state output channels. Logic Solvers and termination blocks install on the 8-wide carrier. Logic Solvers communicate with each other through the carriers over a two-channel, local peer bus (SISnet) and remote peer ring. Local Logic Solvers are hosted by the same DeltaV controller and remote Logic Solvers are hosted by a different DeltaV controller. Logic Solvers are powered by a 24 V DC power supply that is separate from the power supply that drives the DeltaV controller and I/O. Logic Solvers install in odd-numbered slots (1,3,5,7) on the 8-wide carrier. Redundant Logic Solvers use four slots. DeltaV SIS Logic Solver February 2021 /deltavsis 3 SISNet Repeaters extend communication beyond the local Logic Solvers connected to one DeltaV controller and broadcast global messages to remote SLS 1508 Logic Solvers through a fiber-optic ring Carrier extender cables extend Local Bus power and signals between 8-wide carriers. Local peer bus extender cables extend the local peer bus (SISNet) between SLS 1508 Logic Solvers on different carriers. 1-wide carriers with terminators terminate the local peer bus at the final carrier. For additional information please consult DeltaV SISNet Repeater product datasheet. Communication Control Network: The DeltaV Control Network provides communication between the nodes in the DeltaV network. Refer to the Installing Your DeltaV Digital Automation System manual for complete information on the Control Network. Local Bus: The Local Bus provides communication between DeltaV controllers and SLS 1508 Logic Solvers and between DeltaV controllers and SISnet Repeatersthe same DeltaV
