CK6163S CNC Torno Paralelo Lathe machine
| US$24,500.00-28,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
CK6163S
Guide Rail
Horizontal Guide Rail
Tool Holder
Electrical four tool-station
Power Source
Electric
Controlling Mode
CNC
Automatic Grade
Automatic
Setting Mode
Floor-type
Precision
High Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Transport Package
Pallet
Specification
2900x1700x1750mm
Trademark
PLOTO OR OEM
Origin
China
HS Code
8458110000
Production Capacity
3000 Sets/Year
Product Description
| Specification | Unit | CNC6136 | CNC6140T | CNC6150B | CNC6150H | CNC6163B | CNC6163C | CNC6180C | |
| Max.swing diameter over table | mm | Φ400 | Φ400 | Φ520 | Φ520 | Φ630 | Φ650 | Φ820 | |
| Max.swing diameter over carriage | mm | Φ200 | Φ210 | Φ305 | Φ305 | Φ380 | Φ380 | Φ450 | |
| Width of guide rail | mm | 310 | 340 | 400 | 400 | 400 | 550 | 550 | |
| Distance between centers | mm | 550 | 850 | 850/1350/1850/2850 | 850/1350/1850/2850 | 850/1350/1850/2850 | 850/1350/1850/2850 | 1350/1850/2850 | |
| Feed | X axis travel | mm | 190 | 210 | 260 | 260 | 320 | 350 | 400 |
| Z axis travel | mm | 750 | 1000 | 1000/1500/2000/3000 | 1000/1500/2000/3000 | 1000/1500/2000/3000 | 1000/1500/2000/3000 | 1500/2000/3000 | |
| X/Z axis rapid traverse | m/min | 10/6 | 10/6 | 8/6 | 8/6 | 8/6 | 8/6 | 8/6 | |
| Spindle | Spindle nose | A2-6 | A2-6 | A2-8 | A2-8 | A2-8 | A2-11 | A2-11 | |
| Thru-hole diameter | mm | Φ58 | Φ70 | Φ82 | Φ82 | Φ82 | Φ105 | Φ105 | |
| Spindle speed | r/min | 30-2500 (stepless) | 30-2500 (stepless) | 65-210,195-220. 510-1600 | 30-2000 (stepless) | 65-210,195-220. 510-1600 | 14-175,40-500. 100-1000 | 20-80,40-180. 90-360,200-800 | |
| Chuck size | inch | 8 (manual) | 10 (manual) | 10 (manual) | 10 (manual) | 10 (manual) | 12 (manual) | 12 (manual) | |
| Turret | Tool-station | 4, Opt.6 | 4, Opt.6 | 4, Opt.6 | 4, Opt.6 | 4, Opt.6 | 4, Opt.6 | 4, Opt.6 | |
| Tool size | mm | 25x25 | 25x25 | 25x25 | 25x25 | 25x25 | 30x30 | 30x30 | |
| Tailstock | Tail type | manual | manual | manual | manual | manual | manual | manual | |
| Tailstock quill diameter | mm | Φ60 | Φ60 | Φ75 | Φ75 | Φ75 | Φ75 | Φ75 | |
| Tailstock sleeve taper hole | M.T.#4 | M.T.#4 | M.T.#5 | M.T.#5 | M.T.#5 | M.T.#5 | M.T.#5 | ||
| Travel of tailstock sleeve | mm | 140 | 140 | 150 | 150 | 150 | 150 | 150 | |
| Motor | Main motor | kW | 5.5 | 7.5 | 7.5 | 11 | 7.5 | 11 | 11 |
| X Axis motor | kW | 1.3 | 1.3 | 1.8 | 1.8 | 1.8 | 1.8 | 2.3 | |
| Z Axis motor | kW | 1.5 | 1.5 | 2.3 | 2.3 | 2.3 | 2.3 | 2.3 | |
| Coolant motor | W | 120 | 120 | 120 | 120 | 120 | 120 | 120 | |
| Positioning accuracy | Unidirectional | mm | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 |
| Repeat | mm | 0.005 | 0.005 | 0.005 | 0.005 | 0.005 | 0.005 | 0.005 | |
| Dimension(L*W*H) | mm | 2070x1370x1800 | 2350x1470x1680 | 2800x1550x1640 | 2800x1550x1850 | 2800x1550x1850 | 3000x1700x1700 | 3600x1700x1800 | |
| Net weight | kg | 2000 | 2300 | 2800 | 3000 | 3000 | 4300 | 5600 | |
| Controller | GSK980 TDi | ||||||||
Standard Accessories:
1. Manual 3 jaw chuck
2. Manual tailstock
3. 4-position electrical turret
4. Servo main motor
6. GSK 980TC3 controller
