Plastic Recyling Machine/Washing Line-Suke Machine

Product Description

Plastic Recyling Machine/washing Line
Description:
The plastics recycling and granulating production line is used to sieve, grind clean and granulate the waste and dd polyethylene, chemical thread, PE-PP and other of less than 2mm thickness thermoplast. According to the requirements of clients, the output of this line could be from 80kg/h to 450kg/h.
The plastics recycling and granulating production line:
1. The beautiful appearance, compact structure, save space;
2. The world first-class DC or frequency conversion control system and segmentation fault alarm, facilitate testing maintenance;
3. The high performance of the deceleration torque distribution system, ensure the equipment running reliable peace;
4. Flexible air cooled/oil cold system reduces the operation cost;
5. Optimization design, elaborate screw, barrel have extremely good plasitcization effect;
6. In order to ensure the quality of the melt, under the precondition of the ability to get out to maximize reflect.
Application and strong point:
The plastics recycling and granulating machine is used to sieve, grind clean and prill the waste and old
Polythylene, chemical thread, PE-PP and the other 2mm thick thermoplast.
According to the requires of clients, the output of this line is from 80kg/h to 450kg/h
If you want more details about this production line,please contact us.

Main Technical Parameters:
Model	SJ-90	SJ-100	SJ-110	SJ-120
Screw Diameter	Φ 90	Φ 100	Φ 110	Φ 120
Screw L/D Ratio	20: 1 -22: 1	20: 1 -22: 1	20: 1 -22: 1	20: 1 -22: 1
Screw Rotary Speed	10-100r/min	10-100r/min	10-100r/min	10-100r/min
Main Motor Power	22kw	30kw	37kw	45kw
Output	68kg/hr	95kg/hr	120kg/hr	135kg/hr
Machine Weight	2600kg	2800kg	3000kg	3200kg
Cover Dimension	4000× 1500× 1800	4000× 1500× 1800	4000× 1500× 1800	4000× 1500× 1800

TRADE TERMS Payment Term: 30% for prepayment by T/T, 70% for balanced payment by T/T, or L/C can be acceptable Delivery Time: 40 days after receipt of prepayment. Packing Method: Packing film or wooden case Guaranteed Time: 12 months
MACHINERUNNING TEST AND AFTER SERVICE When machine finished, we will invited client come to our factory to check the machine and do the machine test. If machine is ok, then client pay for the balance. And inspect machine load the container. When machine arrives client's factory, if client needs, we will send 1-2 engineer to client's factory do the machine installation and running test, and also train the local worker how to operate and maintain the machine. It is chargeable. If have any question or problem on machine operation or maintain, welcome to contact to us by email or calling. We stand by 24 hours.
