SE-1900V Eco-friendly Efficiency Precision Energy-saving Intelligence All Electric Injection Molding Machine

Product Description

All Electric Injection Molding Machine

Performance characteristic:
Zero-resistance clamping injection guider structure, heavy loaded guider device supported by linear track, better wear resistance, lower friction and more smooth operation. Optimize mold structure, tie bar no touch with moving platen,no lubrication. The system has high rigidity and strength, guarantee the accuracy of platen parallel excellently.

T-slot & screw fixation platen embedded moldlocating ring design, high-standard clampling system reduces mold loss and makes more easy mold installation.
Fast and smooth mold movement, high torque, less resistance. Clamping servo motorconnects ball screw, flexible operation and simply maintenance. High- quailty belt, warranty 10 years;superior rotating wheel,low inertia.
Top responsibility servo motor and high toreque ball screw is key element, origin Japan technology to keep advantage leading ir the word, precise for mold movement.
Parameter:

MODEL			SE-1900V
CLAMP TONNAGE		kN	1900
SPACE BETWEEN Tl E-BARS		mm	580x530
PLATEN DIMENSION		mm	820x800
OPEN STROKE		mm	470
MOULD THICKNESS		mm	200-600
EJECTOR STROKE		mm	130
EJECTOR FORCE		kN	39.2
EJECTOR NUMBER			9
MACHINEWEIGHT		T	8.6
SCREW DIAMETER		mm	36	40	45	40	45	50	45	50	55
INJECTION CAPACITY		cm3	173	214	270	232	294	363	366	452	546
INJECTION WEIGHT (PS]		g	157.5	194.4	246	212	268	331	333	411	497
PLASTICIZING CAPACITY (PS)		kg/h	71	91	123	91	123	150	123	150	175
SCREW SPEED		rpm	350			350			350
HEATER BAND			3+1			3+1			4+1
HE/JER POWER		kW	10.3			12.3			14.4
NOZZLE PRESSING FORCE		kN	29.4			29.4			29.4
STANDARD			450			570			790
INJECTION SPEED		mm / s	200			200			200
INJETION RATE (PS)		cm3 /s	204	251	318	252	318	393	318	393	475
INJECTION PRESSURE		Mpa	258	210	165	265	210	170	247	200	165
		kgf/cm2	2636	2135	1687	2700	2135	1730	2519	2040	1686
MAX.INJECTION HOLD PRESSURE		Mpa	207	167	132	213	168	136	197	160	132
		kgf/cm2	2109	1708	1345	2169	1714	1388	2015	1632	1349
TOTAL POWER		kW	40.3			42.3			68.4
OPTION			450H			570H			790H
INJECTION SPEED		mm / s	350			350			350
INJETION RATE (PS)		cm3 /s	357	440	557	441	557	688	557	688	831
INJECTION PRESSURE		Mpa	258	210	165	265	210	170	247	200	165
		kgf/cm2	2636	2135	1687	2700	2135	1730	2519	2040	1686
MAX.INJECTION HOLD PRESSURE		Mpa	207	167	132	213	168	136	197	160	132
		kgf/cm2	2109	1708	1345	2169	1714	1388	2015	1632	1349
TOTAL POWER		kW	64.3			66.3			86.3
We reserve the right to change specifications without prior notice.

OVERALL DIMENSIONS
PLATEN DIMENSIONS
Application:
The SE series of all-electric injection molding machine are more suitable for household appliance, medical,electronic optics, packaging,auto parts, and other industries with its advantages of high speed, high efficiency, high precision, energy saving and environment cleaning .
