A Grade Jinko 590W 620W 625W 660W N Type Bifacial Soalr Panel
Basic Info.
Model NO.
JKM570-590N-72HL4-BDV
Number of Cells
72pcs
Application
Solar System
Condition
New
Certification
ISO, CE, TUV, IEC
Material
Monocrystalline Silicon
Cell Type
N Type Mono-Crystalline
Weight
31 Kg (68.34 Lbs)
Junction Box
IP68 Rated
Frame
Anodized Aluminium Alloy
Transport Package
Carton & Wooden Pallet
Specification
2278*1134*30mm
Trademark
Jinko
Origin
China
HS Code
8541430000
Production Capacity
50000PCS/Month
Product Description
Product DescriptionProduct Parameters
| Module Type | JKM580N-72HL4-BDV | JKM585N-72HL4-BDV | JKM590-72HL4-BDV |
| Maximum Power (Pmax) | 580Wp | 585Wp | 590Wp |
| Maximum Power Voltage (Vmp) | 43.88V | 44.02V | 44.17V |
| Maximum Power Current (Imp) | 13.22A | 13.29A | 13.36A |
| Open-circuit Voltage (Voc) | 52.50V | 52.70V | 52.90V |
| Short-circuit Current (Isc) | 13.95A | 14.01A | 14.07A |
| Module Efficiency STC (%) | 22.45% | 22.65% | 22.84% |
| Operating Temperature( ) | -40~+85ºC | ||
| Maximum system voltage | 1000/1500VDC (IEC | ||
| Maximum series fuse rating | 30A | ||
| Power tolerance | 0~+3% | ||
Product detail
Product packaging
| Type | pallet | 40HQ |
| JKM570-590N-72HL4-BDV | 36PCS | 720PCS |
