Kc CE UL Approved Li-ion Battery Charger 58.8V 5A Electric Scooter Battery Charger
Basic Info.
Model NO.
FY5805000
Charger Application
Tablet, Laptop, Video Game Player, MP3/MP4 Player, Camera, Standard Battery
Nominal Voltage
294W
Charger Style
USB Charger
Compatible Battery Type
AAA/AA
Size
233*108*64 mm
Certification
SASO, GOST-R, KC, PSE, CTIA, RoHS, TUV, CB, CE
Socket Type
UK, USA, EU
Recyclable
Recyclable
Output Voltage
58.8V
Output Current
5A
Product Weight
1.6kg
Efficiency
>88%
Leadtime
2-3weeks
Protections
Short Circuit Overload Overvolt
Color
Black
Transport Package
White Box+Export Carton
Specification
Depending on the quantity
Trademark
Fuyuang
Origin
China
HS Code
8501310000
Production Capacity
500000PCS Per Month
Packaging & Delivery
Package Size
30.00cm * 11.00cm * 7.00cm
Package Gross Weight
2.200kg
Product Description
| Product name | KC KCC Approved Li-ion Battery Charger 58.8V 5A Electric Scooter Battery Charger Module |
| Type | FY5805000 |
| Output voltage | 58.8V |
| Output current | 5A |
| Output Power | 294W |
| Product Size | 233*108*64 mm |
| Product Weight | 1.6kg |
| Input voltage | 100-240V |
| Frequency | 50/60Hz |
| Pressure test | 3mA 3000VAC |
| Reliability | 25°C 30,000 hours |
| Certificate | CCC ,UL, cUL ,CE, GS, PSE ,SAA , RCM, KC, KCC, CB, TUV ,ROHS |
| Lead time | samples 5days, mass protection 15-20days |
Application ♦ Electric vehicle, Ebike, Electric Scooter, Mortor, Golf car, car jumper
♦ Solar Systems, Home Application,UPS
♦ LED Torch, headlight, Portable power bank,etc.
Electrical Specification
♦ Universal Input: 100 - 240V AC, 50/60Hz
♦ Input Plug: EU US UK AU South Korea South Africa Power cords
♦ Output Voltage Range of main products: 4.2~60V DC (Optional)
♦ Output Current Range of main products: 0.5-100A (Optional)
♦ Output: 58.8V 5A
♦ Charge mode: CC--CV ( Li-ion battery charger)
All Chargers for lithium ion battery pack
4.2V for 1S 3.6V lithium ion battey pack
8.4V for 2S 7.2V lithium ion battery pack
12.6V for 3S 10.8V lithium ion battery pack
16.8V for 4S 14.4V lithium ion battery pack
21V for 5S 18V lithium ion battery pack
25.2V for 6S 21.6V lithium ion battery pack
29.4V for 7S 25.2V lithium ion battery pack
37.8V for 9S 32.4V lithium ion battery pack
42V for 10S 36V lithium ion battery pack
54.6V for 13S 46.8V lithium ion battery pack
67.2V for 16S 57.6V lithium ion battery pack
84V for 20S 72V lithium ion battery pack
♦ Led display: Red--in charging; Green--fully Charge
♦ Cut-off Current: 10-15% of Charge current
♦ Output Connector: 3pin Aviation Plugs, XLR socket, DC Jack, Alligator Clips, SAE connector, Anderson Plugs, RCA
♦ Ripple & Noise:1% of Output Voltage
Mechanical Specification
♦ Size: 233*108*64 mm
♦ Type: Desktop Type
Safety Certification
♦ CCC,
♦ KC
♦ PSE
♦ SAA, C-Tick
♦ UL /cUL. FCC
♦ CE. CB. GS. BS1363, ROHS
♦ TUV
Energy Standard
♦ MEPS
♦ CEC-V
♦ ERP V
♦ Energy Star: Level 6
♦ Standby Power: <0.3W
Protection Function
♦ Over voltage protection
♦ Over current protection
♦ Over-load protection
♦ Short circuit protection
Environmental Protection
♦ RoHS , REACH , CPSIA or PAHs Compliant On Request
Operation And Storage Condition
♦ Operation Temperature: -20°C to 40°C
♦ Operation Humidity: 20% to 90% R.H
♦ Storage Temperature: -20°C to 75°C
♦ Storage Humidity: 1% to 90% R.H.
♦ MBFT: > 50,000Hours
