SM-150T Small Model European Design Servo Energy Saving Injection Molding Machine

SM-150T Small Model European Design Servo Energy Saving Injection Molding Machine

US$17,000.00-20,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
SM-150T
Type
Preform Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Certificate of Origin
1
Certificate of Fumigation
1
Packing List
1
Commercial Invoice
1
Easy Broken Parts
1
Transport Package
Wooden Pallet and Dust Cover
Trademark
K&E
Origin
China
HS Code
8477101090
Production Capacity
500/Y

Product Description

Product Description: Introducing the SM-150T Horizontal Small Automatic Servo Energy Saving Plastic Pet Bottle Preform PVC Tubes Servo European Design Injection Molding Machine. This preform injection machine is perfect for producing plastic products with precision and efficiency. With its advanced servo technology, it ensures energy savings while delivering high-quality results. Trust K&E Machinery for reliable installation, debugging, and after-sales service. Warranty: 12 months for the machine and 6 months for easy broken parts.
Parameters:
SPECIFICATION SM-150
SCREW TYPE A B C
Injection Unit
Screw diameter mm 38 42 45
Screw L/D ratio L/D 24.3 22 20.5
Shot volume(theoretical) CM3 227 277 318
Injection weight(PS) g 206 252 289
Injection rate g/s 100 122 140
Injection pressure Bar 2127 1741 1517
Screw speed rpm 230
Clamping Unit
Clamping force KN 1500
Open stroke mm 380
Space between tie-bars(W*H) mm 470*420
Max mould height mm 500
Min mould height mm 160
Ejector stroke mm 120
Ejector force KN 50
Others
Max pump pressure Bar 16
Motor pump power Kw 18.2
Heating power Kw 7.9
Machine dimension(L*W*H) M 4.66*1.27*1.65
Oil tank cubage L 250
Machine weight Ton 4.5

Product Description: K&E Machinery (Ningbo) Co., Ltd. presents the Sm-150t Horizontal Small Automatic Servo Energy Saving Plastic Pet Bottle Preform PVC Tubes Servo European Design Injection Molding Machine. This injection molding machine is perfect for producing plastic products, with a focus on preform injection. It offers excellent after-sales service, including engineer installation and debugging. The machine comes with a 12-month warranty, with easy broken parts covered for 6 months. Experience the benefits of servo technology and energy-saving design with this high-quality injection molding machine.
Items Brand/country
Servo
System
Controller TECHMATION -8' (TAIWAN )
Servo Motor INOVANCE (CHINA)
Servo Drive INOVANCE (CHINA)
Oil Pump ECKERLE (Germany) or SUMITOMO (JAPAN )
Electric
Unit
Stroke transducer NOVO or FLTCH (Germany)
Breaker Schneider (France ) or LS (Korea )
Contactor Schneider (France ) or LS (Korea )
Air Switch Schneider (France )
Location /Speed Sensor Schneider (France )
Hydraulic
Unit
Hydraulic Direction Valve YUKEN (Japan)
Proportion back-pressure valve North man (Taiwan)
Plasticizing hydraulic Motor DAN DUN (ITALY)
Hydraulic Hose MANULI(ITALY) or GOOD YEAR (USA)
Hydraulic Sealing ring All Italy and Japan
Others
Unit
Mechanical safety Standard
Electric safety Standard
Mold close fast Standard
Injection Unit Linear guide-way
Air core 1pcs
Hydraulic Core 1pcs
T slots and screw holes Standard
Servo system Compared with the other manufacturers is big, Overload ability strong and stable.
