W-Rr1350m Sanding Machine 1350mm UV Line Drum Belt Sander
| US$13,999.00-23,999.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
W-RR1350M
Automatic Grade
Automatic
Variable Speed
Variable Speed
Certification
CE, ISO
Customized
Customized
Condition
New
Color
Customized
After-sales Service
Lifetime
Max. Sanding Width
1350mm
#1 Sanding Unit
Rubber Roller/11kw-15kw
#2 Sanding Unit
Rubber Roller/11kw-15kw
Roller Hardness
20-35shore
Roller Dia.
320mm
Transport Package
Pallet
Specification
1350mm
Trademark
Valentina Exim
Origin
China
HS Code
846593
Production Capacity
500
Packaging & Delivery
Package Size
230.00cm * 230.00cm * 230.00cm
Package Gross Weight
3800.000kg
Product Description
Veneer Sanding Machine/Lacquer Sander/ Wide Belt Sander/Drum Sander
Model W-RR1350M
Configuration
Sanding Unit #1: Rubber Roller
Sanding Unit #2: Rubber Roller
Electrical Parts
Main motors with thermal relay protection; SIMENS PLC MCGS/ SIMENS Touch screen. Main bearing: NSK/TR Pneumatic components AIRTAC (TAIWAN) Optoelctronic switch: BANNER/AB (USA) Safety Protection
3-color caution light; Emergency stop button on both in-feed and out-feed ends; Belt error/pressure error/ feeding error/ protection. Product Parameters
| MAX. WORKING WIDTH: | 1300mm |
| MIN. WORKING LENGTH: | 270MM |
| WORKING THICKNESS: | 3-100MM |
| FEEDING SPEED: | 6-30M/MIN(FREQUENCY CNOTROL) |
| MACHINE DIMENSION: | 2150*2175*2130mm |
| MACHINE WEIGHT: | 3600Kg |
1# SANDING UNIT
·Type: Rubber Roller
·Dia : Φ215mm-320mm
·Motor: 11kw -15kw
·Belt Speed : 3-12m/sec (frequency control)
·Adhesive Belt Size:1390*2100mm
2# SANDING UNIT
·Type: Rubber Roller
·Dia : Φ215mm-320mm
·Motor: 11kw -15kw
·Belt Speed : 3-12m/sec (frequency control)
·Adhesive Belt Size:1390*2100mm Detailed Photos
Packaging & Shipping
You are welcome to contact us for different material sanding technology consulting. Application
1. Lacquer sanding
2. Floating structure, suitable to UV Line
We have done sanding solutions for wooden panels,acoustic panels, metal sheet, veneer sheet, PCB boards sanding, funiture,door,flooring,plywood,MDF/HDF, particle boards, etc. manufacturers.
