European Standard Used Tire Retreading Equipment to Pyrolysis Oil Making Plant Without Pollution Used Tyres Oil Refining Equipment, Scrap Tires Pyrolysis
| US$1.00-111,111,111.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
JC-LH
Certification
CE, ISO
Condition
New
Customized
Customized
Automatic Grade
Automatic
Structure
Horizontal
Ass
Y
COM
Y
Ship
Y
PLC
Y
Transport Package
Wooden Case
Specification
40 HQ
Trademark
FINEYEAR
Origin
China
HS Code
84778000
Production Capacity
166 Per Year
Product Description
Motorcycle tyre tread cooling cutting production line:Application: This machine is mainly used for cooling and collecting tyre tread or sidewall of bias tyre and radial tire after extruding.
Structure Features: This machine is mainly composed of take-up, contraction, constinuous weighting, marking, calendaring and sticking base system, cooling, speed set point setting, cutting, accelerated separation, water blow-off, inspection, spreading and spraying rubber cement, pick-up device etc., and designed according to the domestic and foreign advanced technologies, with speed regulation by AC frequency conversion, PLC control, entire line synchronization, no stretching for products.
| Model | TMX |
| Line speed | 5 ~ 25m/min |
| Take-up height | 900mm |
| Width of production roller | 650mm (design according to tread width) |
| Pick-up temperature | ≤ 40ºC (Ambient temperature + 5ºC) |
| Cutter: Max. thickness of tread cutting | 20mm |
| Max. cutting width | 450mm |
| Range od cutting angle adjustment | 35° ± 5° |
| Length tolerance of the cutting component | ± 3 |
| Cutting frequency | 10 ~ 15 cuts/min |
| Pressure of compressed air | 0.6 ~ 0.8 Mpa |
| Total motor power | 23.3KW |
| Cooling water consumption | 50 ~ 60 m3/h |
| Dimension (L*W*H) | 28000*2000*2800mm |
| Weight | 20000kg |
