Rrt3yk6020 Crawler Mobile Screening Plant

Product Description

Product Description Runtianzhike's mobile screening station is a highly efficient screening equipment that uses a crawler drive walking mode. It has advanced technology, complete functions, strong power, and convenient transportation, making it suitable for complex and ever-changing construction environments.Because of its unique optimized dynamic design and intelligent process control system, it has a strong, durable, stable and reliable high efficiency screening capacity.
Application scenario: Widely used in screening operations in various crushing and screening processes, including material screening in mining sites, and aggregate screening in crushed asphalt and concrete mixing stations for solid waste resource utilization, such as building demolition, road concrete recycling, and other material screening in various industries.
Detailed Photos
Product Parameters

RRT3YK6020 Crawler Mobile Screening Plant
Feeding Device	Max.feeding Size 150mm
	Feeding Height 2400mm
	Hopper Volume 3m³
	Feeding Capacity 300t/h
Feeding Conveyor Belt	Belt Width B1000mm
Screener	Screening Area 6000mm*2000mm
	Number of Sieve Layers 3
Coarse Material ConveyingBelt	Belt Width B500mm
	Power 4kW
Medium-Sized Material Conveying Belt	Belt Width B500mm
	Power 4kW
Fine Material Conveying Belt	Belt Width B500mm
	Power 4kW
Filler ConveyingBelt	Belt Width B1000mm
	Power 4kW
WholeMachine	Total Power 49.5kW
	Total Weigh 32t
	Processing Capacity 120-300t/h
	Working Dimension 12.7mx13.0mx5.9m
	TransportationDimension 14.5mx3.5mx3.8m
