UV Resin Is Used for Rapid Bonding of Glass and Plastics

Product Description

Product profile
GM728 is a single-component, UV-cured, acrylate adhesive. The product is designed for PCB circuit board, glass, metal and various plastic surfaces. After the covered material surface with moisture, insulation, dust, corona and other functions. Typical applications are PCB circuit board, solar panels, and other industries.
Product characteristics Extensive bonding materials, to a variety of circuit board substrate, plastic, glass, metal and other materials have a very high adhesion The glue surface curing (surface drying) is fast, and the high power ultraviolet lamp can quickly achieve the surface debonding effect The flexibility formula can coat soft circuit boards and soft plastics Low viscosity, permeability, and can be applied to mechanical spraying Motion-proof, high temperature resistance, high humidity, ultraviolet resistance, the product performance in harsh environment Gel performance
Light yellow and transparent liquid in appearance
viscosity
(@25ºC, Rotational viscometer) 200-250mPa.s
condition of cure
The following data are measured at the infinite LED lamp intensity of 120 m w / cm²:
Table drying time (s) 15
Deep curing time
(36W UV,1mm,s) 5
Complete curing energy of 800-1000 mj / cm²
physical and chemical performance
The following data are measured after the cumulative energy of 1000 mj / cm²:
Hardness (Shao D) 75 ± 2

type	model number	Product Description	Color	Viscosity	Curing method	Radiating energ(mJ/cm2)	Hardness	Usage temperature
UV glue	HD 1232UL	Flame retardant UV adhesive	canary yellow	10000cps	UV	1200	55D	-40~120ºC
	GM 3231	High temperature resistant UV adhesive	canary yellow	8000cps	UV	1200	75D	-40~200ºC
	GM 9000	Printed circuit board with fluorescent coating	transparent	400cps	UV+moisture	2000	75D	-40~120ºC
	JOM 3190	SMD inductor, magnetic steel	canary yellow	4800-7200cps	UV+anaerobic	2000	84D	-40~120ºC
	GM263	PVC cable fixing	transparent	10000cps	UV	1200	40D	-40~120ºC
	GM3239	High transparency, glass bonding	transparent	1000cps	UV	1200	85D	-40~120ºC
	GM6026	Adhesive for attaching wires	blue	1500-3000cps	UV	1200	2A	-40~120ºC
	GM 246	UTG glass cladding	transparent	1800cps	UV	1200	40D	-40~120ºC
	JD 5339	Transparent low shrinkage	transparent	550cps	UV+120ºC 60min	3000-6000	86D	-40~150ºC
	JD 5627	High strength, low shrinkage	milky white	95000cps	UV+130ºC 30min	3000-6000	93D	-40~180ºC
	GM9687	AA process adhesive, UV+thermosetting	black	120000-140000cps	UV+80ºC 60min	3000-6000	92D	-40~150ºC
	JM4857	Peelable adhesive	blue	155000-230000cps	UV	1200	55A	-40~120ºC
	GM5109	Hydrolyzed glue	canary yellow	30-50	UV	1200	70D	-40~120ºC

1. Are you a factory or trading company?
Yes. We are factory focus on the development and application of polymer materials and high-end electronic adhesives.
2.Any OEM/ODM service ? JOME can offer the customer OEM label service,and will give the protection of the your right in your market.
3.How to be JOME's distributor ? As the growing of JOME's global business,we need to find more and more distributors and agents worldwide. JOME will provide the best solution and service for our partners. For more information, pls contact with us directly 4.How to get samples ? Contact with us to get samples 5.Delivery time ? Normally, delivery time of sample order is 3 to 7 days, standard order is 7-20 days. 6. How to proceed an order?
Firstly let us know your requirements. Secondly we quote according to your requirements or our
suggestions. Thirdly customer confirmed the details and pay deposit for order. Fourthly we arrange
the production then you pay balance to us before shipment.
7. Shipment:
By Express: DHL, UPS, Fedex, TNT, EMS, Ect.
If your order is big, we'll advise you to use Air or Sea shipping through your nominated forwarder
agent.Our long-term cooperated agent is also available.
