Automatic Paper Cup Machine for Making Coffee Paper Cup
Basic Info.
Model NO.
RD-3600A
Cup Size(Ounce)
2oz-32oz
Speed
40-60pcs/min
Required Paper
Single and Double Side PE Coated Paper
Automation
Automatic
Logo Printing
With Logo Printing
Certification
CE
Customized
Customized
Condition
New
After-sales Service
After-Sales Service
Machine Speed
56-60 PCS/Min
Model
Rd-3600A
General Power
8kw
Cups Weight
2-32oz
Paper Weight
180-350GSM
Transport Package
Wooden Case
Specification
2600x1200x1580mm
Trademark
KEDE
Origin
China
HS Code
8441309000
Packaging & Delivery
Package Size
260.00cm * 120.00cm * 158.00cm
Package Gross Weight
3000.000kg
Product Description
Manufacturrer of Automatic coffee/ milk/ hot/cold drinking paper cup forming /making machinespeed 56-60pcs/min PLC control PE/PLA coated paper cup machine
Product Description
3600A automatic paper cup forming machine is our latest machine,which is made base on our manufacturing experience and advanced technology from oversea countries, it is a pioneer equipment . The machine comes with rectangle tube and channel steel welding structure, which is stronger and small deformation, automatic lubrication system, which makes all mechanical parts working much more smoothly. The cup bottom adopts the stretching die which make the bottom sealing quality better and less leaking percentage. It has PLC control, sensor failure detecting system, cup bottom paper feeding controlled by servo motor, bottom paper will be delivered when cup tube comes, otherwise no bottom paper delivery. The machine has safety guard to protect the people working safely, it is the best choice for making paper cups. Product Parameters
| Cups Specifications: | 2-32oz |
| Paper Specifications: | 180-350g/m² |
| Speed: | 55-60pcs/min |
| Power supply : | 380v 50Hz /220 50HZ |
| General Power : | 8KW |
| Gas source: | 0.3-0.5m³/min |
| Weight: | 2500kg |
| Packing Dimensions: | 2600x1200x1580mm(LxWxH) |
