Vmc855 Vertical Machining Center Made in China

Product Description

Product Description
Introducing the state-of-the-art 4-axis VMC-850, an exceptional CNC vertical machining center, meticulously crafted by Liaocheng Wayne New Materials Co., Ltd. This formidable machine embodies superior characteristics of high rigidity, exceptional speed, and precise accuracy, outshining its peers in both operation and capability. Each casting is subjected to a secondary tempering process, ensuring unparalleled rigidity and stability throughout the system. Designed with a high-rigid 'C' structure, it features enhanced reinforcement on machine ribs. The precision is preserved by manually scraped contact surfaces, guaranteeing enduring accuracy. The X/Y axes offer two versatile rolling guideway options: ball bearing or roller, customizable to meet specific customer requirements. The Z axis adopts a roller guideway, delivering unmatched rigidity, minimal noise, and reduced friction. Equipped with a convenient air tank for manual water drainage, the machine boasts a direct spindle connection achieving speeds up to an astonishing 10,000 RPM, making it the ideal choice for efficiently machining intricate components.

Main Features
Advanced Mitsubishi M80 control system Spindle engineered for high speed and precision Superior chip flushing system for optimal performance Innovative structure design Outstanding rigidity throughout the entire machine Optimal worktable dimensions: 500mm x 1000mm Impressive worktable load capacity: 200kg

ITEM	MODELS	VMC850
WORKTABLE (WIDTH*LENGTH)	mm	500x1000
DISTANCE BETWEEN T SLOTS	mm	5-18x100
MAX LOAD BEARING OF WORKTABLE	kg	600
X/Y/Z AXIS TRAVEL	mm	800/500/500
DISTANCE FROM SPINDLE NOSE TOWORKBENCH	mm	110-810/110-610
SPINDLE HOLE TAPER	-	BT40
SPINDLE SPEED RANGE	r/min	12000
SPINDLE MOTOR POWER	kW	7.5
X/Y/Z RAPID FEED SPEED	m/min	36x36x36
MAX CUTTING FEED SPEED	mm/min	12000
TOOLS MAGAZINE CAPACITY	pcs	24
X/Y/Z POSITION ACCURACY	mm	0.005
X/Y/Z RE-POSITION ACCURACY	mm	0.003
MACHINE DIMENSION	mm	2495x1970x2360
MACHINE WEIGHT	kg	5000

Standard Configuration for VMC Series 1. Comprehensive Full Cover Shield
2. Sophisticated self-lubrication system
3. Efficient working lights
4. Alerting warning lights
5. Working condition warning indicators
6. Automatic self-powered electrical shutoff system
7. Multi-functional clean air gun, water tank, and transformer
8. Spindleequipped with air curtain and dust control system
9.High-performance 10,000 RPM spindle
10. Convenient worktable cleaning water gun
Optional Configuration for VMC Series 1. High-capacity 24-disc manipulator tool magazine
2.Efficient crawler chips remover
3. NCrotary table (4 Axis) for versatile machining
4. CTS
5. State-of-the-art Tooldetection system for precision assurance
6,. AJO
7. High-speed 12,000 & 15,000 RPM direct connection spindle
8. Efficient oil mist purifier for clean operation
Detailed Photos

Packaging & Shipping
Company Profile
Liaocheng Wayne New Materials Co., Ltd. stands proudly at the pinnacle of CNC Router and Laser Engraving & Cutting technology. Nestled in the vibrant and innovative hub of Liaocheng city, Shandong, our extensive and diverse product line showcases an impressive array of state-of-the-art machinery. This includes Large-scale ATC Woodworking Router Machines that redefine efficiency, advanced 5-axis CNC Router Machines offering unparalleled precision, reliable CNC Advertising Router Machines for seamless branding solutions, precise CNC Marble Engraving Machines for artistic stonework, efficient CNC Plasma Cutting Machines for industrial applications, and cutting-edge CNC Metal Mold Machines. We also offer versatile CNC Lathe Machines, high-precision Swiss Type Lathe Machines, powerful Fiber Laser Cutting Machines, versatile CO2 Laser Cutting & Engraving Machines, state-of-the-art Laser Marking Machines, and highly effective Laser Welding Machines, among others. By harnessing cutting-edge technology and maintaining unwavering quality standards, we are dedicated to building the global brand 'Wayne.' Our superior craftsmanship has propelled our products to reach over 100 countries, including key markets like the United States, Germany, Indonesia, Canada, Australia, Russia, and extensively across Southeast Asia. This remarkable global presence solidifies our position as a true international leader in our field.
At Liaocheng Wayne New Materials Co., Ltd., our core mission is to provide unparalleled service excellence to our esteemed customers. Whether you require off-the-shelf solutions or custom configurations, we excel in delivering precisely tailored solutions that meet your unique needs. Each component of our state-of-the-art machines is meticulously sourced from world-renowned suppliers and pioneers in machine control, ensuring not only exceptional performance but also unmatched reliability. Our machines seamlessly integrate into a variety of industries and artistic endeavors, such as woodwork, intricate metal and stone work, aluminum fabrication, boat building, shop fitting, and precision mold making. Supported by a dedicated and highly skilled after-sales service department, an adept sales team, and stringent quality assurance protocols, you can purchase from us with absolute confidence. We warmly invite customers and potential business partners worldwide to join us in cooperative ventures, paving the way for mutual success. By offering the best service, impeccable quality, and competitive prices, Wayne stands as your ultimate choice. We eagerly look forward to collaborating with you to generate greater value. Reach out to us with your requirements, and let's engage in a fruitful conversation. We patiently await your contact, ready to embark on a promising journey together.
Certifications

FAQ
1. Is it all right to make customer's own brand name? A: yes. we are available with OEM

2. Are you a manufactuer or trading company?
A:We are the manufacturer with Laser machine and CNC lathe machine

3. Can you do the design for us?
A: yes. if you want a different control system design or higher column , we are available.

4 . What is your terms of delivery?
A: FOB Qingdao.

5. What's your payment term?
A: T/T OR L/C at sight.
If you want to learn more latest catalog with price list or question ,please contact with me !
