X5036 Good Price Manual 3 Axis Dro Vertical Milling Machine Tools for Sale
| US$4,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
X5036
Structure
Bed type
Milling Cutter Type
Vertical Milling Cutter
Controlling Mode
Program Control
Automatic Grade
Automatic
Precision
High Precision
Certification
GS, CE, ISO 9001
Condition
New
Transport Package
Wooden Box Packaged
Specification
X5036
Trademark
SIECC
Origin
Jiangsu/China
Production Capacity
1000 Sets/Year
Product Description
This machine has the following features:1.X5036A vertical milling machine body adopts advanced cast iron, the high precision, long life after the artificial aging treatment
2.X5036A vertical milling machine spindle rigidity, strong bearing capacity, the bed is a rectangular guide bed, good stability.
3.X5036A vertical milling machine X, Y to the control of the machine tool by box type, can achieve automatic feeding, Z to the use of motor automatic lift.
4.X5036A vertical milling machine X, Y, Z three direction of the guide rail hardening, precision grinding. Plastic slide
After the motion precision and life and taste
5.Equipped with manual lubrication device can be used to guide screw and guide rail.
6.X5036B vertical milling machine is a kind of common metal cutting tools. This tool spindle cone can be directly or through the attachment of cylindrical milling, installation, end milling cutters, Angle cutter knives, applicable to such processing various parts of the plane, cant, groove, holes etc, machinery manufacturing, mould, instrument and meter, automobile, motorcycle industries ideal processing equipment.
The main specification of the machine
| SPECIFICATIONS | X5036A | X5036B |
| Spindle taper | 7:24 ISO50 | 7:24 ISO50 |
| Distance.spindle to tabie surface mm | 80-440 | 70-450 |
| Spindle center to column guideway surface distance mm | 320 | 360 |
| Spindle speed range r/min | 60-1700(12) | 60-1690 (12) |
| Mill Head rotation angle | ±45° | ±45° |
| Table size mm | 1250×360 | 1500×360 |
| Table travel (X/Y/Z) mm | 600/320/360 | 1000/320/380 |
| Table longitudinal/lateral Speed of mm/min | 22-555(8)810() | 15-370(8)540() |
| Table vertical speed motor movements mm/min | 590 | 590 |
| Table T-slot number/width/spacing mm | 3/18/80 | 3/18/80 |
| Main motor power kw | 4 | 4 |
| Table motor power feed motor w | 750 | 750 |
| Lift motor power down feed w | 1100 | 1100 |
| Cooling pump motor powe w | 90 | 90 |
| Cooling pump flow | 25 | 25 |
| Machine NW/GW (kg) | 2200/2400 | 2230/2400 |
| Overall size(mm) | 1700×1680×1880 | 2220×1790×1980 |
| Company | Shining Industrial Enterprise(China) Co., Ltd Nantong Brillante Industrial Enterprise Co., Ltd Edward Pearson Machinery (Shanghai) Co., Ltd NANTONG LIANZHONG MACHINE CO., LTD JIANGSU GOLD-PARTNER ENTERPRISE CO.,LTD |
| Brand | SIECC/EDWARDS PEARSON/HECTMAC |
| Website | braillante.en.made-in-china.com braillante.en.made-in-china.com braillante.en.made-in-china.com braillante.en.made-in-china.com |
| Video | 1. Rolling https://youtu.be/Fi3tFKSoLlY 2. Press brake https://youtu.be/pyIChKoh1eA 3. Grooving https://youtu.be/pFZh_n3vrss 4. Ironworker https://youtu.be/0O9OeCmu9QI 5. Plasma cutting https://youtu.be/71BKxv6tVB8 |
| | |
| https://braillante.en.made-in-china.com | |
