HAWKER Linde L12 2PZB200 24V200Ah
HAWKER Linde L12 2PZB200 24V200Ah
The traction forklift battery produced by hawker | power supply Co., Ltd. is the most advanced technology and process at present, and also the most widely used product in the industry. For example, many famous brand manufacturers such as forklift trucks, locomotive tractors, electric cleaning vehicles and electric tour buses use hawkerpzs traction batteries. It conforms to DIN standards and mainly supports European standard forklifts such as Linde, Hangcha, JUNGHEINRICH, Hyster, BT and still. It conforms to JIS / BS standards and mainly supports JIS / BS standard forklifts such as nichiyu, Toyota, TCM, Komatsu, shinko and Nissan.
Monomer structure
Hawker traction battery uses mature tube positive plate technology. The positive plate adopts die-casting grid, and the active material is stored in a row of tubes made of polyester material; The negative electrode plate is a reinforced plate electrode plate. Between the positive and negative electrode plates, there are micropores and a raised diaphragm on one side. The battery cell shell is made of polypropylene material with high impact resistance and high temperature resistance, and the shell cover is heat sealed to prevent electrolyte leakage.
Pole terminal
Each positive and negative terminal is made of lead alloy and copper core terminal with internal thread. The cooperation between the pole and the compressed sealing rubber ring can effectively prevent the leakage of electrolyte.
Battery cell connecting strip
The battery cells are connected by fully insulated halogen-free flexible connecting strips. The method of fixing the connecting bar with bolts can make it easy and fast to take out the unit from the battery pack for maintenance or replacement.
Safety valve
Each battery cell is equipped with a safety valve to allow the gas generated during charging to escape. The operation of adding purified water and measuring the specific gravity of electrolyte can be carried out through the safety valve. The safety valve also has a baffle for the battery to prevent electrolyte surge.
Battery cover
The battery cover has a design that an electrolyte agitation system or a temperature sensor can be installed after punching.
Hawker aquamatic centralized automatic water adding system
Hawker aquamatic centralized automatic water adding system can add water to all battery cells in the battery pack from the central point of the battery system. As shown in the previous figure, the water filling safety valve of the system can automatically maintain the optimal liquid level of the battery cell, and also allow the gas generated during charging to escape and measure the specific gravity of electrolyte.
Electrolyte agitation system
Hawker electrolyte circulation agitation system works by using the air lifting principle and the pipeline system installed on the battery. The diaphragm pump blows the low-speed air flow into the battery, so that the air flow circulates in the battery case. This system can effectively prevent electrolyte stratification and ensure charging optimization.
advantage
● higher capacity under the same overall size
● higher discharge efficiency
● longer operation time and higher reliability
● in terms of capacity and size, it effectively integrates din and BS standards in European standards
Hawker traction battery for charged hydrolysate agitation system
● avoid electrolyte and temperature stratification during partial or full charging
● optimize the charging acceptance process of the positive and negative plates of the battery, so that the bearing capacity of the positive and negative plates is consistent
● compared with the traditional charging method, the charging time is reduced by 30% and the energy consumption is reduced by 20%
● avoid electrolyte and temperature stratification during partial or full charging
● optimize the charging acceptance process of the positive and negative plates of the battery, so that the bearing capacity of the positive and negative plates is consistent
● compared with the traditional charging method, the charging time is reduced by 30% and the energy consumption is reduced by 20%
Electrolyte layering and electrolyte circulation
Hawker ® The dimensions of traction battery pzs (with bolt firm connection bar) comply with DIN / en 60254-2 and iec254-2 'l' series standards.

	(5h)	(mm)			（+/-5% kg)
		L	W	H
2 PzS 120	120	47	198	370	8.4
3 PzS 180	180	65	198	370	11.8
4 PzS 240	240	83	198	370	15.5
5 PzS 300	300	101	198	370	19.0
6 PzS 360	360	119	198	370	22.5
7 PzS 420	420	137	198	370	26.1
8 PzS 480	480	155	198	370	29.8
9 PzS 540	540	174	198	370	33.5
10 PzS 600	600	192	198	370	37.8
2 PzS 160	160	47	198	435	9.8
3 PzS 240	240	65	198	435	14.0
4 PzS 320	320	83	198	435	18.1
5 PzS 400	400	101	198	435	22.6
6 PzS 480	480	119	198	435	26.6
7 PzS 560	560	137	198	435	31.1
8 PzS 640	640	155	198	435	35.2
9 PzS 720	720	174	198	435	42.1
10 PzS 800	800	192	198	435	46.8
2 PzS 180	180	47	198	505	12.0
3 PzS 270	270	65	198	505	16.9
4 PzS 360	360	83	198	505	21.6
5 PzS 450	450	101	198	505	26.3
6 PzS 540	540	119	198	505	31.1
7 PzS 630	630	137	198	505	36.1
8 PzS 720	720	155	198	505	40.8
9 PzS 810	810	174	198	505	45.5
10 PzS 900	900	192	198	505	50.3
2 PzS 230	230	47	198	575	13.6
3 PzS 345	345	65	198	575	19.4
4 PzS 460	460	83	198	575	25.2
5 PzS 575	575	101	198	575	31.1
6 PzS 690	690	119	198	575	36.9
7 PzS 805	805	137	198	575	42.7
8 PzS 920	920	155	198	575	48.6
9 PzS 1035	1035	174	198	575	54.3
10 PzS 1150	1150	192	198	575	60.2

	(5h)	(mm)			（+/-5% kg)
		L	W	H
2 PzS 250	250	47	198	600	14.3
3 PzS 375	375	65	198	600	20.5
4 PzS 500	500	83	198	600	26.9
5 PzS 625	625	101	198	600	32.9
6 PzS 750	750	119	198	600	39.4
7 PzS 875	875	137	198	600	45.8
8 PzS 1000	1000	155	198	600	51.5
9 PzS 1125	1125	174	198	600	57.7
10 PzS 1250	1250	192	198	600	64.0
2 PzS 280	280	47	198	715	19.1
3 PzS 420	420	65	198	715	25.4
4 PzS 560	560	83	198	715	32.9
5 PzS 700	700	101	198	715	39.9
6 PzS 840	840	119	198	715	47.2
7 PzS 980	980	137	198	715	54.8
8 PzS 1120	1120	155	198	715	62.3
9 PzS 1260	1260	174	198	715	71.0
10 PzS 1400	1400	192	198	715	76.7
2 PzS 310	310	47	198	750	19.1
3 PzS 465	465	65	198	750	25.6
4 PzS 620	620	83	198	750	33.6
5 PzS 775	775	101	198	750	42.1
6 PzS 930	930	119	198	750	50.1
7 PzS 1085	1085	137	198	750	58.2
8 PzS 1240	1240	155	198	750	66.3
9 PzS 1395	1395	174	198	750	74.5
10 PzS 1550	1550	192	198	750	81.3
