2y-25/5 F Crawler Type CPT Machine/Cptu Machine

Product Description

2Y-25/5 F Crawler Type CPT Machine
CPT machine uses hydraulic rams to push the CPT probe into the soil ground in even speed. The resistance of the cone probe penetrating soil, producing the changes of the electric resistance into the signals of quantity of electric charge, which is sent to the computer on the ground to record, analyze and give out the geotechnical engineering properties of soil and delineating soil stratigraphy. It is used in soft soil, adhesive soil, clay, sandy soil etc.
2Y-25F-5 hydraulic crawler has good features of the similar products in the market. It has compact structure, small size, large power and:
1. Use the crawler to support and move, can work in tough working environment such as beach, river bank, sand lands, paddy fields etc., and can walk on the icy roads.
2. Advanced hydraulic system, compact structure, small size, easy to install, small loss to the pressure etc.
3. Use sliding hydraulic anchoring system, big torque hydraulic motor to rotate the anchor legs into the ground. When doing CPT, the anchoring system can slide out the vehicle, and slide back after finish CPT work.
4. For shallow depth CPT test, no need to do anchoring, just use the small CPT machine on the vehicle.
5. This machine can lift itself up by their hydraulic ram legs, can be easily to load on/off transportation vehicles.
6. The machine is multiple purpose, it is not only an ideal equipment for CPT, but also can be used for CPTU, PMT, DMT, VCT, WVT testings(corresponding accessories are required)

Walking Speed	10-30 km/h	Gradeability		≤30°
Track Type	Rubber	Track Width		350mm
Track Pitch	82P	Track Tooth Qty		55Z
Engine Power	Diesel, 22KW	Engine Speed		2000-2500 rpm
Hydraulic System	Oil Pump	Model		CB-Fc315-FL-YZ
		Rated Speed		2000 rpm
		Displacement		60 L/min
		Pressure		16 Mpa
	Multiple Unit Valve	Model		DL15CF.50WC.C
Supporting Legs	Hydraulic Cylinder Ram Diameter			90mm
	Stroke			450mm
	Bearing Capacity(single cylinder ram)			60 KN
	Lifting Force(single cylinder ram)			40 KN
CPT Apparatus	Type			2Y-25 or 2Y-5
	Rated Thrust Force			250KN or 50KN
	Lifting Force			300KN or 60KN
	Penetration Speed			1.2±0.3 m/min
	System Oil Pressure			10 Mpa
Anchoring System	Anchoring Motor max Torque			2442 N.m
	Anchoring Type			Multiple anchors
	Anchor Diameter			≥350 mm
Probe Pipe	Material: High Strength Steel Alloy 45MnMoB
	Diameter: Φ36. Φ40,Φ42(Optional)
Temperature	Ambient Temperature Maximum				40ºC
	Ambient Temperature Minimum				-20ºC
	Engine Water Temperature				<90ºC
	Hydraulic Oil Temperature				<65ºC
Dimension	3300*1750*1800mm		Weight		3800kgs
