1x1m tube settler plate hexagonal honeycomb slope tube sheet lamella tube inclined settler media

Product Description

Product Description
Product Overview1x1m tube settler plate hexagonal honeycomb slope tube sheet lamella tube inclined settler mediaThe hexagonal honeycomb slope tube produced by our company uses EPR copolymer plastic as the material,it was hot drawn into hexagonal tube by a infrared thermal machine,and then using patented technology and high frequency to weld into a whole product,our staff will carry on-site installation for the customer.Inclined tube is mainly used for a variety of precipitation and sand removing.For a decade,it is a water treatment device that's widely used in the drainage works.It has the advantages of being suitable for a wide range,high treatment efficiency,small footprint.FEATURES AT A GLANCE1x1m tube settler plate hexagonal honeycomb slope tube sheet lamella tube inclined settler media1. Loose sheets tube settler2. Tube settler block3. PP tube settler and PVC tube settler4. White color, Blue color or Black colorLoose SheetsTube Settler BlockTube Settler SamplePRODUCT SPECIFICATIONSNoItemData1Sheet Size1000mm*1000mm, 1000mm*1500mm2Aperture25mm, 35mm, 50mm and 80mm3Thickness0.4mm, 0.45mm, 0.5mm, 0.6mm, 0.7mm, 0.8mm, 0.9mm, 1mm, 1.2mm.4MaterialPP material or PVC material1. Large wetted perimeter, hydraulic radius is small.2. The laminar good condition, particles falling from flocculent flow interference.3. When the tube for 1 m long, effective load by 5 tons/square meter design.And V control in 2.5- 3.0 mm/SEC effluent water,within the scope of the best.4. In the water inlet place inclined pipe length, the honeycomb 2.0-3.0 meters, may in the 50-100 kg/m3 clay sand content of high turbidity safe operation of processing.5. The plastic inclined packing, which the processing ability is to destabilize the flat streaming traps three to five times, accelerate the clear pool and pulse clarify pool two to three times.6.The material is with UV radiation protection.50mm aperture tube settler80mm aperture tube settlerPRODUCT CONFIGURATIONElectrical Iron:It need use electric iron to weld the loose sheets tube settler to blocks.Successful ProjectPackage and shippingTube Settler PackageWe always pack loose sheets tube settler on pallet with film wrap.FAQQ: Are you a trading company or a manufacture factory? A: Our factory found in 2016, it's professional manufacturer in China Q: What is your payment terms ? A: Normally ,30% as the deposit first by T/T, the rest 70% will be paid before shipping by T/T. Q: How about your delivery time?A: Urgent inquiry accept. <50 cubic meter, within 7 days <200 cubic meters . within 15 days <500 cubic meters, within 20 days
