CCA Conductor Speaker Cable/Wire Cable

Product Description

SPECIFICATION:
COPPER WIRE CONDUCTOR

Color- Coded PE/PVC Insulation Insulation Wraped with or without Polyester Tape Rip Cord: Synthetic Fiber Shield: AI/PET Foil Optional Drain Wire: Solid Or Stranded Bare Copper Jacket: PVC or LSZH PE/PVC Insulated & PVC Jacketed Un-shielded Alarm Cable C.S.Area Construction Insulation Jacket Overall (mm2) Core x No./Dia. Thickness(mm) Thickness(mm) Diameter(mm) 2*0.22 2*7/0.20 0.2 0.7 3.9 4*0.22 4*7/0.20 4.4 6*0.22 6*7/0.20 5.0 8*0.22 8*7/0.20 5.4 10*0.22 10*7/0.20 6.2 12*0.22 12*7/0.20 6.4 14*0.22 14*7/0.20 6.6 16*0.22 16*7/0.20 7.4 20*0.22 20*7/0.20 7.8 2*0.20 2*1/0.50 0.2 0.7 3.1 4*0.20 4*1/0.50 3.6 6*0.20 6*1/0.50 4.2 8*0.20 8*1/0.50 4.6 10*0.20 10*1/0.50 5.3 12*0.20 12*1/0.50 5.5 14*0.20 14*1/0.50 5.9 16*0.20 16*1/0.50 6.3 20*0.20 20*1/0.50 6.9 2*0.28 2*1/0.60 0.2 0.7 3.9 4*0.28 4*1/0.60 4.5 6*0.28 6*1/0.60 5.0 8*0.28 8*1/0.60 5.7 10*0.28 10*1/0.60 6.0 12*0.28 12*1/0.60 6.4 14*0.28 14*1/0.60 6.8 16*0.28 16*1/0.60 7.6 20*0.28 20*1/0.60 8.2 PE/PVC Insulated & PVC Jacketed Un-shielded Security Alarm Cable with Power Cords C.S.Area Construction Insulation Jacket C.S.Area Construction O.D. Overall (mm2) Core x No./Dia. Thickness(mm) Thickness(mm) (mm2) Core x No./Dia. (mm) Diameter(mm) 2*0.22 2*7/0.20 0.2 0.7 2*0.50 2*16/0.2 1.6 5.4 4*0.22 4*7/0.20 6 6*0.22 6*7/0.20 6.4 8*0.22 8*7/0.20 7.2 10*0.22 10*7/0.20 7.5 12*0.22 12*7/0.20 7.6 2*0.22 2*7/0.20 0.2 0.7 2*0.75 2*24/0.2 1.8 6.0 4*0.22 4*7/0.20 6.6 6*0.22 6*7/0.20 7.0 8*0.22 8*7/0.20 7.8 10*0.22 10*7/0.20 8.0 12*0.22 12*7/0.20 8.2 *Above charter shows only the typical cables, customized order are also welcome! Factory photos and production processOur Service: 1) Quick Response --All inquiries will be replied within 24 hours. 2) Professional Quotation --All prices will be quote according to customers' detailed specifications & requirements. 3) OEM & ODM Service 4) Can print your own brand on the jacket printing with foot or meter marking. 5) Make customized designs for stickers, drums, outer cartons, etc. 6) Stable Quality --All materials and products passed restrict QC procedures,comply with international standards. 7) Fast Delivery --LCL orders,15days after confirmation; FCL orders, 20 days after Confirmation in usual. Good After-sales Service --We chose the fastest vessel to POD for delivery our goods to clients,--All Documents will be issued according to clients' instructions, to save troubles from local customs.--Any complaint to quality or packing issued will be responded, and terminated with proper solutions for clients. FAQ: Q1: What kind of cable do you produce?A: We specialized in producing Coaxial Cable,Network Cable,Patch Cord,CCTV Cable,Optical Fiber Cable, Speaker Cable,Alarm Cable,Telephone Cable,Drop Wire,Audio Cable,HDMI Cable,Control Cable etcWe also provide cable accessory products such as connector, cable clip,cable tie,crimping tool, antenna dishe,splitters,amplifer,optical receiver,optical transmitter etc Q2: What's your MOQ? Can you offer free samples?A: Our MOQ is 10KM per item. Free samples can be sent to you if available in stock,freight cost need to be paid by your side. Q3: What's your delivery time?A: Normally, our delivery time is 15 days after received deposit,it base on the quantity of the order. Q4: What's your payment term?A: We accept T/T, L/C,Western Union.Other payments accept through negotiation. Q5:What's your trade term?A: We accept FOB ShangHai or Ningbo,CFR,CIF,EXW term Q6: Where is your factory located? How can I visit there?A: Our factory is located in Lin'An HangZhou City,ZheJiang Province,China.1 hour drive from HangZhou XiaoShan International Airport3 hours drive or 1 and half an hour by high speed rail to railway station from shanghai or Ningbo

CCA CONDUCTOR WIRE HOT IN MIDDLE EAST MARKET

model( size)	Specification Description	Insulation Out Dia.	Jacket/sheath Material Colour
		(mm)
0.5mm2	2x20/0.18mm	O. D:2.5x5.0	PVC/Transparent or any
0.75mm2	2x30/0.18mm	O. D:2.8x5.6	PVC/Transparent or any
1.0mm2	2x32/0.20mm	O. D:3.2x6.4	PVC/Transparent or any
1.5 mm2	2x48/0.20mm	O. D:3.8x7.6	PVC/Transparent or any
2.0mm2	2x64/0.20mm	O. D:4.0x8.0	PVC/Transparent or any
2.5mm2	2x50/0.25mm	O. D:4.4x8.8	PVC/Transparent or any

CHARACTERISTIC:
1) Different series of zips and twist wires
2) Product range: 10GA, 12GA, 14GA, 16GA, 18GA, 20GA and ultra classic strands
3) Conducot available:100% (Tinned)Bare copper wire,copper coated al,
4) PVC material available:simplex color pvc(Red,Black,Blue,White and so on),transparence and so on
Packing:
a) Packing lengths: 100m/roll, 200m/roll, 305m/roll
b) Inner packing: wooden drum, plastic drum, paper drum
c) Outer packing: carton box, pull out box
d) Other packing available according to customer
Special cables can be made according to your requirement.Welcome to negotiate OEM with us!
Application:
These cables are used in connecting for audio appliances, home appliances, small electric tolls and instruments.
Construction: Stranded copper conductor, PVC insulated, twin parallel or twisted.
Voltage: 300/500V

PACKING:
carton,plastic spool,soft cloth etc
