Copper Based Machined Parts C18150/C18200/C18000/C17510/C17200/C17300

Product Description

Product Description

C17300 BERYLLIUM COPPER (Chemical composition(%)

Be	1.8-2.1
Co	0.2(min)
Pb	0.2-0.6
Si	0.2(max)
Al	0.2(max)
Cu	Balance

Oilfield tools

Aerospace land gears

Robotic welding

Spot weld

Mold making application

Electrical shafts

Nonsparking safety tools

Welding equipment, Flexible metal hose

Nickel Beryllium Copper (C17510)

Chemical composition(%)	Co	Ni	Be	Cu
	0.3	1.4-2.2	0.2-0.6	Balance

Material Characteritics

High thermal and electrical conductivity

Good strength and hardness

High tensile strength

Very high hardness

Typical applications

Electrodes for spot welding, especially for stainless steel

Electrodes for projection welding

Butt welding jaws

Contact tips for submerged-arc-welding

Plunger tips for horizontal die-casting machines

Molds for NF-metal castings

Welding equipment

Current carry shafts

Plastic injection mold tooling

Robotics

Current carry bushings

Copper Chromium Zirconium (C18150/CuCrZr/CW106C/2.1293)

Chemical composition(%)

Cr	0.5 - 1.5%
Zr	0.02 - 0.2%
Cu	Balance

Material characteristics

Corrosion resistant

High electrical conductivity

High strength

High hardness

Deformation resistant

Resistance welding electrodes

Seam welding

Flash and butt welding dies

Welding gun arms, welding platens, molds, spot welding tips, seam welding shafts

Caps and shanks, Circuit breaker parts

Collector connector, collector housing, connector bar, connector lead bars

Cross-wire welding electrodes and components, Electrode holders and adaptors, Power generation products,

Transmission devices

Detailed Photos
Company Profile RICH BASE TECHNOLOGY Co., Limited was founded in 2007. We are a professional and forerunner in China's copper alloy
R&D and manufacturing. Our management team has nearly 20 year's experiences in the field of copper alloy manufacturing
and CNC machining.
The copper alloys we supply include
Chromium zirconium copper(C18150),
Chromium copper(C18200),
Nickel silicon chromium copper (C18000),
Nickel beryllium copper(C17510, C17500),
Beryllium copper(C17200, C17300),
Zirconium Copper(C15000, C15100),
Tellurium Copper (C14500),
Oxygen free copper (C10100/C10200),
copper nickel alloys(C79200/C79400) etc...The forms we manufacture include Round bars, square bars, rectangular bars, hexagonal bars, and different types of plates and sheets per customers' requirements. We not only manufacture different sizes/shapes of copper alloys, we also manufacture finished products namely cap tips/contact tips/seam wheels/resistant electrodes, and other customized products based on our alloy, please contact us for your requirements. With more than 20 years of copper alloy R&D and manufacturing experiences, coupled with a full range of manufacturing equipment. Our manufacturing process starts with raw materials and ends with customized shapes/forms of copper alloys. This enables us to supply high-quality copper alloys at very competitive prices. Over the past years, we have earned a worldwide reputation for high-quality materials at competitive prices, quick deliveries, and superior services. Our materials are being exported to Europe, North America, North-east Asia, South-east Asia etc. Quality is an essential part of our manufacturing operations, our highly trained quality assurance team will do all necessary testings and inspections to make sure that all materials meet customers' requirements and expectations before shipping the materials to our customers. Our copper alloys are mainly used in the automobile industry, aerospace industry, aircraft industry, appliance industry, consumer electronics, electronic equipment, electrical connectors, electrical equipment, foundry products, industrial machinery, machine tools, resistance welding industry, telecommunication industry, transportation (high-speed train), etc. Our materials are used by Volkswagon, Toyota, Hongda, Ford, China high-speed trains, etc. For any inquiry, please contact our sales representative.
