DIN3202 F1 En1092-2 Pn10 Pn16 BS En558 F1 ANSI as 2129 Table D E Ductile Spheroidal Graphite Nodular Ductile Cast Iron Di SS304 316 Screen Y-Strainer Filter

Product Description

DIN3202 F1 EN1092-2 PN10 PN16 BS EN558 F1 ANSI B16.1 AS 2129 TABLE D E Ductile spheroidal graphite nodular Cast Iron Y-Strainer Filter

Nominal Pressure	1.0MPa	1.6MPa
Pressure Test for Sealing	1.1MPa	1.76MPa
Pressure Test for Shell	1.5MPa	2.4MPa
Working Temperature	-10~80ºC
Suitable Medium	Water, Oil, Gas

No	Part	Material	Standard
1	Body	Ductile Iron	GGG50
2	Screen	Stainless Steel 304/316	DIN SS304/316
3	Body Gasket	EPDM/Graphite
4	Bolts	Steel	DIN RRST37-2
5	Cover	Ductile Iron	GGG50
6	Plug	Stainless Steel	DIN SS304

Company Profile:
Tianjin Newton Valve Co., Ltd is a reputable valve manufacturer specializing in high-quality valves such as rubber seat butterfly valves, wafer check valves, ball check valves, resilient seat gate valves, cast iron valves for marine applications, and Y strainers. With advanced management systems and certifications including ISO 9001, CE, ISO 14001, DNV, and WRAS, we are committed to producing superior valves, focusing on details and continuous improvement. Our experienced sales team and comprehensive after-sales support ensure client satisfaction. Trust us to deliver exceptional products and service
Our Features: OEM: We're an OEM manufacturer for famous customers in India, Netherlands, Singapore, Thailand, U.A.E, Egypt, Pakistan, Russia, Mexico, Australia etc. Valve Parts Machining: We not only supply valves, but also valve parts, mainly body, disc, stem, and handle. Some of our regular customers keeping ordering valve parts for more than 10 years, we also produce valve parts mold according to your drawing. Machines: We have a total of 07 machines (including CNC, machine center, semi-auto machine, pressure testing machine, water test machine, assembly machine, and spectrograph, etc.) mainly used for valve part machining. Lead Time: If regular valves, our lead time is short because of our huge stocks of valve parts. Normally, it takes 15-20 days. Quality Control (QC): Our regular customers have been working with us for more than 10 years as we always keep our high-level QC for our products. Price Advantage: Our price is competitive because we process valve parts by ourselves.
Quality Control Inspection of Product before shipping/export The third-party inspection: DNV, SGS, BV, CE, and others. During the production process, we perform many quality control tests e.g., Dimensional Inspection, Leakage, Pressure Testing Flow Performance Testing, etc. to make sure that product should have corrosion resistance and appropriate color coating for safe transportation of the products.
Certifications Dedicated staff to facilitate Before / After Sale Service (Video/Representative Support) We can provide ISO 9001, CE/ ISO14001 /DNV/WRAS.
