Jt-850 CNC Milling Machine Heavy Duty CNC Vertical Machining Center
| US$37,000.00-48,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
JT-850
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Point to Point Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
High-End CNC Machine Tools
Condition
New
Precision
High Precision
Standard System
Mitsubishi M80
Speed Range
12000rpm
Feed Rate
15000mm/Min
Transport Package
Seaworthy Packing
Specification
5000kg
Trademark
JT
Origin
China
HS Code
8458110000
Production Capacity
1500 Sets/Year
Product Description
Product Parameters| ITEM | UNIT | JT-850S | |
| Workbench | Workbench size | mm | 1000x550 |
| Worktable load-bearing capacity | kg | 600 | |
| T-slot width (VVidth x spacing x number of slots) | mm | 18x100x5 | |
| Trip | X-axis travel | mm | 800 |
| Y-axis travel | mm | 520 | |
| Z-axis travel | mm | 560 | |
| Distance from spindle end face to workbench | mm | 120-680 | |
| Distanoe from spindle center to Z-axis rail surface | mm | 550 | |
| Principal axis | Speed range | rpm | 12000 |
| Main spindle power (Continuous/30 minute rated) | kw | 7.5/11 | |
| Slope of spindle inner hole | BT40 | ||
| Transmission mode | |||
| Feed | X-axis rapid displacement | m/min | 36 |
| Y-axis rapid displacement | m/min | 36 | |
| Z-axis rapid displacement | m/min | 36 | |
| Feed rate | mm/min | 15000 | |
Automatic tool change system | Tool magazine capacity | set | 24 |
| Maximum tool outer diameter (When fully loaded) | mm | 80 | |
| Expanding the diameter of the hollow blade | mm | 150 | |
| Maximum tool length | mm | 300 | |
| Maximum tool weight | mm | 8 | |
| Tool change time (Knife to knife) | sec | 2.4 | |
| Precision VDl3441 (JISB6338) | Positioning accuracy | mm | P0.01(±0.004/300) |
| Repetitive accuracy | mm | Ps0.008(+0.003) | |
Other | Electricity demand | Kva | 20 |
| Barometric pressure demand (Minimum) | kg/cm² | 6 | |
| Cutting filuid capacity | liter | 250 | |
| Machine footprint | mm(Approximately) | 2400x2675 | |
| Machine height | mm(Approximately) | 2650 | |
| Machine weight | kg(Approximately) | 5000 | |
