Plywood Production Equipment Machine Woodworking Wood Based Panel Machinery

Product Description

Plywood Production Equipment Machine Woodworking Wood Based Panel Machinery
China Shandong famous and professonal factory-Shandong Minghung wood machinery, who produce and offer the full line of plywood production equipment and rotary veneer lathe. As your own conditions and requires, we can offer the suitable and good machinery for you.

VENEER PEELING LATHE

Rotary veneer peeling lathe is very important for making wood veneer. One set good and strong veneer lathe can easily peel kinds of hard wood like beech, birch, pine and others, and make your wood veneer good quality.
The advantages of our veneer lathe:
With good materials and spare parts to make machine is heavy and strong, keep stable; and with many conveniently functions, which improve your production capacity

Max log length	1400mm /2600mm / as customized
Max log diameter	500mm /700mm /customized
Thickness	1-3mm
Speed	Adjustable
Wood species	Beech, birch, pine, eucalyptus, and others

VENEER DRYER

Veneer dryer's function for drying original peeled veneer moisture, make its final moisture be suitable for making plywood and wooden furniture. We can designe the veneer dryer to be different floors, drying width, floors as your drying capacity and other conditions.
The advantages of our veneer dryer:
With high and advanced production technology, the structures of our veneer dryer is mature, keep works very well; Make the dryed veneer good quality
And all of our dryer materials and spare parts are very good

Drying floors	2/3/4/5
Drying width	3000mm /3200mm /4000mm /4500mm
Sections	Can be different as your requires
Veneer thickness	1-3mm
Speed	adjustable
Drying capacity	Different like 40m3, 60m3, 70m3 or as your requires

HOT PRESS MACHINE

Hot press machine is one very important machine for plywood manufacturing, its function for pressing plywood to be solid and strong. Its layers, pressure, size all can be designed as your own conditions.
Advantages of our Hot press machine:
<1> hot press machine frame use thick steel plate, all welding place be grinding finely, make sure machine good quality and beautiful.
<2> The hot platen be processed by large lathe, make the surface is smooth, with sufficient strength and stiffness. Under the high temperature, it will not change its shape, and transfer hear uniformly. This makes the plywood heated evenly, and surface is flat, help you produce good quality plywood.
<3> The oil cylinder is treated with anti-rust, alloy casting, high hardness, scratch resistance, suitable for high-strength operations, and uses a good oil seal to prevent leakage, ensure the pressure in the oil cylinder, and good performance
<4> Hydraulic station is one important part for press machine, Our hydraulic station be designed by our engineer, reasonable design of hydraulic system, save energy, all hydraulic components are arranged reasonably, neatly and beautifully placed, and the components like electromagnetic valve, hydraulic pump all use good one.

Product name	Plywood Hot Press Machine
Layers	8 /10 /12 /15 /20 /25 /30 /35 /40
Pressure	400t /500t /600t /800t /1000t /1200t
Cylinder	φ320*2pcs /φ360*2pcs /φ220*6pcs /φ260*6pcs
Hot platen size	2700*1370*42/52/62mm
Power	18.5kw/29.5kw
Weight	33t /48t

COLD PRESS MACHINE

Cold press machine mainly for pre-pressing plywood after glued veneers. It also can be designed to be different opening as you want.
Advantages of our Cold press machine:
<1> the structure of cold press machine is simple, and easy operate for worker.
<2> the frame of cold press machine uses thick and good one, make sure hydraulic cold press is stable.
<3> The oil cylinder is treated with anti-rust, alloy casting, high hardness, scratch resistance, suitable for high-strength operations, and uses a good oil seal to prevent leakage, ensure the pressure in the oil cylinder, and good performance
<4> Hydraulic station is one important part for press machine, Our hydraulic station be designed by our engineer, reasonable design of hydraulic system, save energy, all hydraulic components are arranged reasonably, neatly and beautifully placed, and the components like electromagnetic valve, hydraulic pump all use good one.

Product name	Cold Press Machine
Pressure	400t /500t /600t
Cylinder	φ320*2pcs /φ360*2pcs /φ220*6pcs
Power	18.5kw
Weight	15T or more
Size	3600*1370*4000mm

GLUE MACHINE

Glue machine for coating glue on wood veneer surface, then your workers can lay the glued veneer out to be required plywood size.
<1> Glue spreader's structure is simple, easy operate.
<2> Transmission by gear & chain, fast speed, high efficiency.
<3> Using good and big diameter roller, good quality

Sides	Double sides at the same time
Size	4feet/8feet or customize
Diameter of coating roller	φ310 /φ410
Line speed	20-30m/min
Installed capacity	5.5kw
Transmission way	gear &chain transmission
Size	2250*1250*1500mm 3250*1250*1500mm

PLYWOOD CUTTING MACHINE

Plywood cutting machine for cutting and trimming plywood edges, make plywood edge be clean, and each plywood size be same.
Advantages:
<1> Be controlled by micro-computer, easy operate.
<2> Be positioning by infrared ray, accurate
<3> Be controlled by PLC, automatic cutting.

Product name	plywood edge cutting saw
size	4*8feet /3*6feet /customize
working speed	40-70m/min
capacity	8-12pcs/min
working style	infrared ray guide
feeding way	automatic

WHY CHOOSE US

Shandong MINGHUNG Wood Machinery is one of the leaders of plywood making machine in China, supplies a complete range of machinery, systems and technology for the production of plywood and veneer including wood debarker, veneer peeling machine, vacuum veneer stacker, knife grinder, veneer dryer machine, glue spreader, cold press, hot press machine, plywood saw machine, sanding machine.
Highly qualified personnel and competent management take all the advantages of production and continue developing day by day, the basis of our business is focus on our clients' needs, such position allows us to build long-term partnership with our clients in China and abroad.
We also works closely with a global network of manufacturing partners in order of provide the reliable, good quality and service to our customers.

MINGHUNG CLIENTS

Untill now, Shandong MingHung machine has exported to many different countries, and got good feedback. such as America, Greece, Romania, Turkiye, Egypt, Indonesia, Vietnam, Africa, Brazil and so on.
We insist only use good materials to make our machine strong, and let our customers satified, help their business going well.
Waiting your message if you need any machine, we will quickly reply you and offer more information
