EPS Styrofoam Foam Cement Precast Wall Panel Production Line Insulated Lightweight Concrete Sandwich Wall Panel Machine Insulation Panel Machine Price for Build

Product Description

EPS Styrofoam Foam Cement Precast Wall Panel Production Line Insulated Lightweight Concrete Sandwich Wall Panel Machine Insulation Panel Machine Price for Build
Product Description
Wall panel for concrete precast houses:
Lightweight sandwiched wall panel providing a solid structure and
superior quality wall finishes to ensure a straight and smooth wall after completion.
They can be used as either a standard structural wall panel, or as a retaining wall section, depending on the requirement on site. The reinforcement steel and foundation detail will alter, depending on the use of the wall panel.
Hongfa wall panel production line has the advantages of being capable of producing various Solid panle, Hollow panels , hollow slabs, wide in production range, convenient to assemble and demould, less in workers, low in labor intensity of workers, high in product yield and accurate in appearance and size. Compared with traditional industry equipment, it is fuller in pouring core material and more convenient to install demoulding shift.
*Light weight----Excellent sound insulation----- Heat Insulation
*Waterproof Fire proof----- Energy Efficient Environmental
*Convenient construction-----High Intensity without deformation.
*It has a solid,lightweight, thin body, high strength, impact resistance, strong hanging capacity, heat insulation, sound insulation, fireproof, waterproof, easy to cut, slot, no need to slap, dry work, environmental protection, etc., widely used in construction.



Product Parameters
Main machine parts for
Sound Insulation Lightweight EPS Cement Sandwich wall panel machine/ eps wall panel machine Lightweight Wall Panel Making Machine /Precast Concrete Wall Panel Machine/Wall Board making Machinery/acoustic wall panel making machine
Hongfa provide main 3 kinds of EPS wall panel machine :
1. Automatic double side opening wall panel machine main data:

Moulding Machine Parameter and Productivity
Overall dimensions(mm)	Power(KW)	Output / Pieces per mould
		60mm	75mm	90mm	100mm	120mm	150mm
3380*3200*2680	4	40pcs	36pcs	32pcs	30pcs	26pcs	22pcs

HFP530A full automatic lightweight concrete wall panel system is Hongfa patent product, for 15 sets molding machine, total production line only needs 5 workers, labor density and intensity is low.
1.Full Automatic
2.Eco Saving and Advanced Technology
3.Low cost and high capacity
4. Easy operation
5. Essy maintainence
6.Adopts touch screen control, automatic filling, electronic weighing, temperature control, material level control to realize automatic production.
One Production line of EPS Foam Cement Panel Machine, Sandwich Panel Production Line, Lightweight Concrete Wall Panel Making Machine Can produce kinds of wall panel:
Raw materials :
Ordinary Portland Cement, Lower Alkalinity Sulfur Acid Salt Aluminum Cement, Polystyrene Foam, Sand, Additives or Fly Ash(Coal Boiler), Water, Perlite, etc.
Main Feasture:

(1)The machine adopts PLC and touch screen control, automatic filling, electronic weighing, temperature control, material level control to realize automatic production.
(2) With the same machine, it can adjust the panel size and thickness. The thickness will be from 60 to 250mm.
(3) The closed constant pressure foamng barrel features of high heating efficiency and saves stem.
(4)High precise guiding pressure reducing valve controls the temperature and steam pressure of the closed barrel, ensuring the outcome pressure of the valve constant and the inner temperature controlled wihin ±1%, which keeps the foamed material equal and prevents the bead agglomerate because of the bad temperature control.
(5)With photoelectric or vibration sensor to control material level, ensuring density tolerance within ±3%.
(6)The machine is equipped with fluidized bed dryer, including drying, automatic sieving, depluming and material conveying to silos.
(7)Most components are of world-famous brands, with reliable performance, stable quality, long service life and low maintenance cost.
(8)The machine can realize the primary and second expansion.
Suggested Staffing Table:

Position	Amount(Person)
Moulding/pouring	1
Demoulding&Packing	1
EPS Expander Operation/raw materials	1
Mixer Operation	1
Transportation	1
Total	5

Successful Kinds of EPS cement sandwich panel making machinery machine
♥ Automatic Vertical Hydraulic & Manually Type Production Line
♥ Horizontal Wall Panel Production Line
Packaging & Shipping
Workshop and shipping Lightweight wall panel production line
