Product Description

Application&Features:
For plastic, rubber, daily chemical and other industries of various materials mixing, stirring, drying, coloring and other process.
1.It is the basic equipment of plastic extrusion production line .
2.Two layers of sealing are adopted in the cover of the mixer and opened in pneumatic mode.The cooling mixer is a vaulted lid, not easy to take shape.
3.The blades have been passed the test of the dynamic and static balance testing machine.
4.Barrel wall undergoes precise grinder.
Main Technical Parameters:

Item Model	Total volume(L)	Effective volume(L)	Rotating Speed (r/min)	Motor power (kw)	Mixing time (min.)
SHR-100	100	75	650/1300	14/22	<=10
SHR-200	200	150	475/950	30/42	<=10
SHR-300	300	225	475/950	40/55	<=10
SHR-500	500	375	430/860	55/75	<=10
SHR-800	800	600	357/714	83/110	<=10
SHR-1000	1000	750	325/650	110/160	<=10
SHR-1500	1500	1100	250/500	160/220	<=10

Scene Pictures:
Zhangjiagang City Chiyu Automation Equipment Co., Ltd focus on building bulk solid handling plant and supplying related machines and fabricated parts to plastic, chemical and petrochemical industry.
Our long suits are the best understanding of bulk material properties and the handling process. We are good at solving problems which exist in bulk solid conveying, storage, weighing, mixing and screening.
Meanwhile, offering optimal solutions and proposals of the whole project . Eventually,
Our company will provide you with an ideal project which acts according to your demands.With comprehensive experience, creative and innovative emotion.
We provide below machines and plants to domestic and international market:
1.High speed mixer and cooling mixer unit,capacity up to 2000 liters for hot mixer and 6000 liters for cooling mixer.
2. Automatic batch weighing and mixing System
3. High precision additives automatic weighing machine
4. Pneumatic conveying system includes: positive pressure conveying system and vacuum conveying system for powder & pellets.
5. Workshop dust removal and environmental protection equipment, etc.
6.Upgrading and transformation of industrial automation system
Automation of bulk material handling systems
Automation and storage, automation and discharge:
The storage of large bulk solids quantities is realised in silos, big-bags and containers, equipped with automatic discharge aids for a safe extraction of the required product amount from the container. In case of larger capacities the bags emptying is made automatically; at smaller discharge capacities the manual discharge process is usually supported by mechanical devices (like hoists ....).
Automation and conveying:
The application of automation technologies in the field of bulk solids transport - comprising both mechanical systems (screw conveyors, bucket elevators, chain conveyors...) and also pneumatic systems (conveying under overpressure and by vacuum, fluidized bed chutes...) - has a very strong impact on production and productivity. It allows to transport even very large bulk quantities in a reliable and safe manner over great distances without human intervention.
Automation and metering, automation and weighing:
In the field of metering and weighing the automation allows higher metering accuracies and has - besides of an productivity increase - mainly an impact on the product quality. Of great importance are the production records and batch protocols recorded and filed by the recipe management system.
Our aim
Total compliance with the technical demands and operating conditions taking into account operating costs and rates of return and wherever possible reducing investment costs.
