Agricultural 90 Degree Bevel Right Angle Transaxle Spindle Hydraulic Pump Mower Pto Motor Speed Increase Reducer Gearbox for Tractor Slasher Rotary Tiller

Product Description

Agricultural 90 Degree Bevel Right Angle Transaxle Spindle Hydraulic Pump Mower Pto Motor Speed Increase Reducer Gearbox for Tractor Slasher Rotary Tiller Product Description
Ocean Group Co., Ltd. is proud to present our Hot Sale Agricultural 90 Degree Farm Pto Right Angle Gearbox. With our years of experience and commitment to providing the best service, ocean have gained the trust of buyers worldwide. →→→Most of our OEM customers usually send their drawings, if you have special request, send us your drawing or send us sample it is also OK.
Features:
1. High-quality construction: Our gearbox is manufactured using modern computerized machinery and equipment, ensuring durability and reliability.
2. Wide range of applications: Suitable for various agricultural machines, including tractor slashers, rotary tillers, PGA feeders, mixers, and earth augers.
3. Efficient speed reduction: The gearbox is designed to provide effective speed reduction, allowing for smooth and precise operation of your machinery.
4. Easy installation: With its 90-degree right angle design, our gearbox can be easily integrated into your existing equipment.
Benefits:
1. Competitive price: We offer our gearbox at a competitive price, ensuring great value for your investment.
2. One-time delivery: We understand the importance of timely delivery, and we strive to deliver your order promptly.
3. Prompt response: Our team is dedicated to providing quick and efficient responses to any inquiries or concerns you may have.
4. On-hand engineering support: We are here to assist you with any technical questions or support you may need during the installation or operation of our gearbox.
5. Good after-sales services: Our commitment to customer satisfaction extends beyond the purchase. We provide excellent after-sales services to ensure your continued satisfaction.
Keywords: Agricultural Gearbox, Helical Agricultural Gearbox, Agricultural Bevel Gearbox, Agricultural Machine Gearbox, Worm Speed Reducer, Worm Gear Speed Reducer, Worm Reducer, Speed Drive, Speed Variator, Planetary Reducer, Planetary Gearbox, Eccentric Reducer, Bevel Gear Reducer, Spiral Bevel Gearbox, Transmission Gearbox, Gear Motor.
Attributes: Suitable for: Reducer, Function: Speed Reduction, Layout Form: Cycloidal.

Item No.	HC-7241
Ratio	3/1
Teeth	10/30
Module	5.0
HP	30
Rated Input	540rpm
Input/Output Description	Hexagon Spline
	Optic Axis
Net Weight	18.5kg

Item No.	HC-7251
Ratio	3.18: 1
Teeth	11/35
MMould	5.08
HP	40
Rated Input	540rpm
Input/OutputDescription	Optic Axis
	Optic Axis
Net Weight	27.5kg

Itern No.	HC-09030-1	HC-09030-2	HC-09030-3
Ratio	1:1.93	1:1.47	1:1.69
Teeth	15/29	15/22	13/22
Module	4.0	5.08	5.0
HP	30	40	35
Rated Input	540rpm	540rpm	540rpm
Input/Output Description	Hexagon Spline(1 3/8 Z6)		Optic Axis
	Cone base aequlate spline shaft
Net Weight	26.5kg	26.5kg	26.5kg

Itern No.	HC-09031-1	HC-09031-2	HC-09031-3
Ratio	1:1.93	1:1.47	1:1.69
Teeth	15/29	15/22	13/22
Module	4.0	5.08	5.0
HP	30	40	35
Rated Input	540rpm	540rpm	540rpm
Input/Output Description	Hexagon Spline(1 3/8 Z6)		Optic Axis
	Cone base aequlate spline shaft
Net Weight	24.5kg	24.5kg	24.5kg

Itern No.	HC-09033-1	HC-09033-2
Ratio	1:1.93	1:1.47
Teeth	15/29	15/22
Module	4.0	5.08
HP	30	40
Rated Input	540rpm	540rpm
Input/Output Description	Hexagon Spline(1 3/8 Z6)
	Cone base aequlate spline shaft
Net Weight	25.5kg	25.5kg

Itern No.	HC-09061-1	HC-09061-2
Ratio	1:1.92	1:1.47
Teeth	14/27	13/19
Module	5.5	7.0
HP	60	60
Rated Input	540rpm	540rpm
Input/Output Description	Hexagon Spline(1 3/8 Z6)
	Cone base aequlate spline shaft
Net Weight	37kg	37kg

Itern No.	HC-09081-1	HC-09081-2
Ratio	1:1.92	1:1.47
Teeth	14/27	13/19
Module	5.5	7.0
HP	60	60
Rated Input	540rpm	540rpm
Input/Output Description	Hexagon Spline(1 3/8 Z6)
	Cone base aequlate spline shaft
Net Weight	43kg	43kg

Itern No.	HC-09100
Ratio	1:3
Teeth	12/36
Module	3.45
HP	30
Rated Input	540rpm
Input/Output Description	Hexagon Spline(1 3/8 Z6)
	Optic Axis
Net Weight	18kg

Itern No.	HC-09259
Ratio	1:3
Teeth	12/36
Module	3.45
HP	30
Rated Input	540rpm
Input/Output Description	Hexagon Spline(1 3/8 Z6)
	Inner Spline ( 36*36 )
Net Weight	15kg

Itern No.	HC-61109-1	HC-61109-2
Ratio	1:1.92	1:1.47
Teeth	14/27	13/19
Module	5.5	7.0
HP	60	60
Rated Input	540rpm	540rpm
Input/Output Description	Hexagon Spline(1 3/8 Z6)
	Cone base aequlate spline shaft
Net Weight	37kg	37kg

Itern No.	HC-09030-1
Ratio	1:1.93
Teeth	15/29
Module	4.0
HP	30
Rated Input	540rpm
Input/Output Description	Hexagon Spline(1 3/8 Z6)
	Cone base aequlate spline shaft Optic Axis 6.35 Flat key
Net Weight	24.5kg

Itern No.	HC-BGB8
Ratio	1:1
Teeth	14/14
Module	6.35
HP	35
Rated Input	540rpm
Input/Output Description	Hexagon Spline(1 3/8 Z6)
	Hexagon Spline(1 3/8 Z6)
Net Weight	19kg

Itern No.	PK.005
Ratio	2.05:1
Teeth	17/25
Module	4.5
HP	35
Rated Input	540rpm
Input/Output Description	Optic Axis
	Optic Axis
Net Weight	31kg

Recommend Products

NMRV Series Transmission Gearboxes

Agriculture Gearbox

WPA WPS Cast Iron Case Worm Gearbox

SWL Elevator Gearbox

ARA Gearbox

PF PLF ZDF ZF Planetary Gearbox

Packaging & Shipping
Ocean Group Co., Ltd. is a professional group manufacturer of a full range of high-quality products including gearbox, gear, gear rack, chain, sprocket, V pulley, timing pulley, coupling, drive shaft, drop forged parts, CNC machined parts, agricultural parts and conveyor line parts. Most of Ocean Oem customers will send their drawings, some will send their sample. Ocean is pride in its capacity to develop products based on individual designs. The group's global stature is reinforced by excelent products and commitment to post-sale service, earning esteemed reputation on the international market. Ocean have extensive experience in serving customers from various regions, with our products being well-received in the American, European, South American, and Asian markets. Manufactured using modern computerized machinery, our products meet international quality standards and are designed for optimal performance.With a focus on competitive pricing, timely delivery, responsive customer service, and comprehensive after-sales support, Ocean ensure customer satisfaction at every step. Our production processes adhere to ISO9001 standards, and Ocean are capable of designing and manufacturing non-standard products to meet specific customer requirements.Quality and credibility are at the core of our business philosophy, and Ocean are committed to providing the best services and top-notch products to our customers. For more information or samples, please reach out to us, and Ocean guarantee a prompt response. FAQ
FAQ:
Q1: Are you trading company or manufacturer ?
A: We are factory.
Q2: How long is your delivery time and shipment?
1.Sample Lead-times: generally 10 workdays.
2.Production Lead-times: 20-40 workdays after getting your deposit.
Q3. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery.
Q4: What is your advantages?
1. Manufacturer,the most competitive price and good quality.
2. Perfect technical engineers give you the best support.
3. OEM is available.
4. Rich stock and quick delivery.
Q5. If you can't find the product on our website,what do you next?
Please send us inquiry with product pictures and drawings by email or other ways and we'll check.
