Three Axies 250CNC Precision Grinding Machine Tool for Metalworking

Product Description

250/2550CNC Surface Grinding MachineThree Axies 250CNC Multifunction Grinding Machine Tool
Adhering to a progressive philosophy, we ensure the constant evolution of our products, retaining the liberty to alter specifications, mechanics, or designs as needed without prior notice or obligations.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd., rooted in the vibrant Dongguan City, Guangdong Province, embodies over 30 years of Taiwanese excellence in grinding machine manufacturing. Our seasoned team leverages this rich heritage and technological prowess to deliver exceptional solutions. Embracing the swift advancements in CNC technology, we spearhead innovation in high-speed, precision-focused, and multi-faceted machine tool development. Our commitment to intelligent solutions, eco-friendly practices, and open systems defines the future trajectory of CNC machinery. Dongguan Chengyu Machinery Technology Co., Ltd. excels in crafting and refining machine tools and accessories. Championing a 'technology-driven, innovative, and trustworthy' ethos, our dedication lies in providing meticulous quality. Understanding our clients' processes and standards, we enhance product utility, leading the numerical control industry with automated, precision-driven, high-quality advancements. Our comprehensive quality management system, state-of-the-art equipment, and exceptional craftsmanship underpin our success. In alignment with market needs, Chengyu Machinery advances the design and fabrication of ultra-precise CNC surface and forming machines, including four-axis punch grinders, vertical sliders, gantry rail grinders, and also offers expertise in robotics and automated production lines. Below is an introduction to our CNC grinding machine series: I. HS series 618 / 250 / 3060 / 4080 / 40100 (servo type / hydraulic type) Processing capacity: Proficient in surface grinding, grooving. Features a proprietary hydraulic control system (hydraulic type). Functionality includes grinding programs for flat surface and groove cutting. Flexible feed modes available: Front, back, left, or right, with memory retention for each grinding program's feed mode. Equipped with a grinding wheel overload protection system for automatic shutdown. II. (servo type / hydraulic type) Processing capacity: Expert in surface grinding, grooving, and integrated scheduling. Incorporates an innovative hydraulic control system (hydraulic type). Comprehensive functions: Surface grinding, groove cutting, sole grinding, side grinding, and unique displacement grinding with varied distance and depth. Automatic dressing and compensation are featured, with options for rough or fine grinding cycles and settings for dressing time and amount. Offers versatile feed modes: Front, back, left, or right, with program-specific memory feed modes. Supports equidistant and varied distance grooving. 3. Four-axis CNC grinding machines are available in both horizontal and vertical formats. Processing types include arbitrary equal division and skipping tooth processing. For waist circle shapes, input dimensions AB for precision. Triangle fillet processing requires input of inscribed circle size B and fillet size R for accuracy. Quadrilateral fillet specifications need inputs for side lengths A, B, and fillet size R. Eccentric circle adjustments require data on eccentricity and the diameters for start and end points. For circular forms, input the starting and ending diameters for precise outcomes. Arc: Simply input the desired size and rotation angle to achieve precision and finesse in your machining process. Effortlessly manage step differences and rotation profiles with unparalleled accuracy, ensuring a flawless finish every time. Save your processing schedule as an easily retrievable file, streamlining future operations and boosting productivity effortlessly.
