Product Description

Stone chip coated steel roofing tile machine
Colorful stone coated metal roof tiles made from Zn-Al galvanized steel (galvalume steel) and painted with colorful stone chips, the main tiles and the accessories are made up of the stone chip coated metal roofing system, this roofing system is popular all over the world.
1.Producing process of our roof tile
Auto Feeding on a conveyor----> 1STglue spraying----->Stone chips dropping---->Loading into a Drying oven---->2 nd Glue spraying- --> Loading into a drying oven---->Finished products of roof tile
2.Component of our production line
Advantage:
1)Reduce glue consumption:the sensor on the glue spraying part,can detect the moving location of the tiles and control the spray gun working on and off automaticly.
2)The enlarged volume of the drying over saved energy and improve speed.The upgrade technology,the drying oven load the roof tile vertically.
3)Cleaning extra stone chip after stone chiping coating reduce the man power.
4)The seonsor to control sand hopper ON or OFF automaticly to reduce the bear of elevator and maxmize equipment life.
3. Technical Performance
1).Manpower Resistant,Climate Resisitant, Aging Resisitant:Painting film without splitting with 100h, without pulverization,without bubbles obvious color changes.
2).Heat resistant:90±2°C without obvious changes
3).Low temperature-Resistant:-40±2°C,24h without obvious changes
4).Water proofing:24h without bubbles without obvious color changes
4,technical parameters of the machine
The following is the details of colorful stone coated metal roofing tile(Classical Tile,Modern Classical Tile,Shingle Tile,Rainbow Tile,Makuti Grained Tile)

Model No.	Zj01	Zj02
Tile size	1400mm*420mm	1340mm*420mm
Installed Exposure	1350mm*370mm	1290mm*370mm
Tiles per Sqm	2sheets	2.08Sheets
Installed Weight	3.0kg/Sheet	2.8kg/Sheet
Quantity in 20FCL	8000PCS	8000PCS

5.Finished roof tile physiochemical index of stone coated metal roofing tile
a.Water resistance:After 24h test without anomalies
b.Heat resistance:No abnormalities after 90°C*5 test
c.Low temperture resistance:After -40°C*24h test without anomalies
d.Alkaline resistance:After 48h test without anomalies
e.Acid resistance:After 48h test without anomalies
f.Resistance salt spry:After 240h test without anomalies
g.Cycle of freezing and thawing:After 20 times test without anomalies
h.Artificial weathering:After 1000h test without anomalies

Colorful stone coated metal roof tiles-circular roof tile A model
1 Raw material of Colorful stone coated metal roof tiles
(1)	Galvalume steel sheet 0.42mm
(2)	Colorful stone chips
2 Size of Colorful stone coated metal roof tiles
(1) overall size	1340mm*420mm
(2) valid size	1270mm*380mm
3 Acreage of Colorful stone coated metal roof tiles
(1) acreage per tile	0.5628SQM
(2)tiles per square meter	1.78pcs
4 Weight of Colorful stone coated metal roof tiles
(1) weight per tile	2.6KG
(2) weight per square meter	5.38KG
5 Packing and loading of Colorful stone coated metal roof tiles
(1) package	400-600pcs/package
(2) loading	9500pcs/20ft container with accessories
6 Color of Colorful stone coated metal roof tiles
(1) normal color	Red; red black; teak; coffee; green; dark green; charcoal black; weathered brown; grey; sapphire.
(2) special color	Can be produced as request
7 Advantage of Colorful stone coated metal roof tiles
(1) Aesthetic:	Two models: flat tile and circular tile, 10 optional colors. Archaize appearance, Chinese style.
(2) durable	Can endure high temperature and low temperature, can resist bad weathers. Zinc-aluminum coating and stone chip coating can anti-corrupt effectively;
(3) sound and heat insulation:	the stone chip can reduce the sound effectively, and can hold back the heat;
(4)easy installations:	Easy to be folded, easy to cut.
(5) light in weight:	The unit weight is about 2.3-2.7kg/piece, just 1/6 as concrete/ clay tile. Easy to be transpo
