Three Axies 250CNC Precision Engineering Grinding Machine Tool for Industries

Product Description

250/2550CNC Surface Grinding MachineIntroducing the Three Axies 250CNC Multifunction Grinding Machine Tool, a pinnacle of precision and versatility tailored for cutting-edge industries.
Our commitment to excellence drives us to perpetually enhance all our offerings. We retain the flexibility to update specifications, mechanics, or designs at any moment without prior notice, ensuring our products remain at the forefront of innovation.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd., established in the bustling hub of Dongguan City, Guangdong Province, brings with it 30 years of rich heritage and expertise in grinding machine manufacturing from Taiwan, supported by a seasoned team of technical experts. This legacy underpins our dedication to precision engineering. In the dynamic realm of CNC machine tools, the evolution towards high-speed, high-precision, composite functions, intelligent control, open architecture, parallel drive systems, network integration, and eco-friendly technologies is redefining the future landscape of the industry. Dongguan Chengyu Machinery Technology Co., Ltd. takes pride in its specialization in the crafting and precision engineering of machine tools and accessories. We are guided by our core principles of 'Technology, Innovation, Reliability' and a meticulous quality policy. Our mission is to deliver superior products and exceptional customer service. By analyzing customer processes, production methods, and quality standards, we design and deploy state-of-the-art production technologies, enhancing product applicability and expanding the CNC industry's horizons. Our product range embodies high automation, precision, and quality, supported by a robust quality management system, top-tier equipment, and advanced technological prowess. To meet burgeoning market demands, Chengyu Machinery innovatively designs and manufactures high-precision CNC surface grinding machines, CNC forming machines, four-axis punch grinders, vertical slider grinders, gantry rail grinders, and industrial robots. Our capabilities extend to automated production lines and integrated solutions. Below is a summary of our CNC grinding machine series: I. HS Series 618 / 250 / 3060 / 4080 / 40100 (Available in Servo and Hydraulic Types) Processing Capacity: Capable of Surface Grinding and Grooving with unparalleled precision. Patented Hydraulic Control System: Unmatched in the hydraulic type category, ensuring superior performance. Functionality: Seamless integration with grinding programs designed for flat surfaces and groove cutting. Feed Mode Options: Choose from front, back, left, or right. Each grinding program memorizes your preferred feed mode for consistency. Safety Feature: Automatic shutdown triggered by grinding wheel overload, ensuring operational safety. II. Ushering in Advanced Grinding: Servo and Hydraulic Types Available Processing Capacity Enhancement: Master surface grinding, grooving, and advanced scheduling with precision. Innovative Hydraulic Control System: Sets the standard for hydraulic performance. Expanded Functionality: Equipped with diverse grinding programs, including surface, groove, sole, and side grinding, as well as advanced displacement grinding options. Grinding Wheel Dressing Excellence: Achieve impeccable bottom plane dressing, with automated rough/fine grinding cycles, ensuring precision. Versatile Feed Mode Selection: Front, back, left, or right, with each program storing your desired mode for efficient operation. Equidistant and Non-equidistant Grooving: Achieve versatile grooving patterns with precision. 3. Four-axis CNC Grinding Machines: Available in Horizontal and Vertical Configurations Processing Versatility: Ideal for equal division and complex tooth-skipping processes. Waist Circle Precision: Simply enter size parameters AB for enhanced accuracy. Triangle Fillet Mastery: Input inscribed circle size B and fillet size R for precise results. Quadrilateral Fillet Precision: Input side lengths A and B, along with fillet size R for optimal outcomes. Eccentric Circle Craftsmanship: Enter eccentricity and diameter parameters for precise circularity. Circle: Enter the starting and ending diameters to achieve precise circular grinding with unparalleled accuracy. Arc: Input the arc size along with the rotation angle to craft arcs with exceptional precision and smoothness. Step Difference & Rotation Profile: Seamlessly manage step differences and rotation profiles for highly customized grinding tasks. Effortlessly save your processing schedule as a file, ensuring a swift and simple recall for future use.
