1100mm PE and Po Film Blowing Machine
| US$13,000.00-14,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
FM-1100
Making Method of Parison
Single Layer Blowing
Automation
Non-Automatic
Computerized
Non-Computerized
Certification
CE, ISO9001:2008
Machine Size
L*W*H: 6.0m*3.3m*5.5m
Voltage
380V 50Hz 3phase
Transport Package
Plastic Warp Film for Container Shipment
Specification
single layer
Trademark
Xiongqiu Plastic Machinery Co., Ltd.
Origin
Foshan, Guangdong Province
HS Code
8477800000
Product Description
It's used to blow various plastic film of low density olyethylene(LDPE), high density polyethylene(HDPE) and linear low density polyethylene(LLDPE), etc.. Widely used for packing food stuff, garment and daily textile, industrial product and agricultural film.| Model | FM-800 | FM-1100 | FM-1300 | FM-1700 | FM-1900 | FM-2200 |
| suitable material | LDPE / LLDPE / HDPE | |||||
| thickness | 0.02--0.20mm | |||||
| film width(mm) | 700 | 400--1000 | 400--1200 | 1600 | 1800 | 2100 |
| max output | 45kgs/hr | 55kgs/hr | 70kgs/hr | 105kgs/hr | 150kgs/hr | 200kgs/hr |
Extruder
| screw diameter | Φ45mm | Φ55mm | Φ65mm | Φ75mm | Φ85mm | Φ95mm |
| L/D ratio | 30:1 | |||||
| temp. controller | 5 zone | 5 zone | 5 zone | 6 zone | 6 zone | 8 zone |
| barrel cooling | 120w*2 | 120w*2 | 120w*2 | 250w*3 | 250w*3 | 250w*3 |
| driving motor | 11kw | 15kw | 22kw | 30kw | 37kw | 45kw |
Die head
| die diameter | Φ150mm | Φ200mm | Φ250mm | Φ350mm | Φ450mm | Φ500mm |
| air ring diameter | Φ250mm | Φ300mm | Φ350mm | Φ450mm | Φ550mm | Φ600mm |
| die structure | Spiral mandrel die chrome plated surface 40Cr | |||||
| cooling fan | 950w | 1.5kw | 2.2kw | 3kw | 4kw | 4kw |
Draging part
| take up width | 800mm | 1100mm | 1300mm | 1700mm | 1900mm | 2200mm |
| effective width | 750mm | 1000mm | 1200mm | 1600mm | 1800mm | 2100mm |
| take up motor | 1.5kw | 1.5kw | 1.5kw | 2.2kw | 2.2kw | 3.7kw |
Winder
| winder width | 800mm | 1100mm | 1300mm | 1700mm | 1900mm | 2200mm |
| effective width | 700mm | 1000mm | 1200mm | 1600mm | 1800mm | 2100mm |
| winder motor | 30kg | 30kg | 50kg | 50kg | 80kg | 100kg |
| optional equipment | auto-loader, film surface treater, fast change net, air compressor, double center rewinder/auto-rewinder, flat cage roll rewinder, rotary die head, double wind air ring | |||||
pictures for reference:
