GE864-QUAD GPRS module for Ingenico POS 5100

Product Description

Product Description
DescriptionGE864-QUAD GPRS module for Ingenico POS 5100GE864-QUAD use for pos machine gprs boardspecifications:The GE864-QUAD AUTOMOTIVE V2 module supports Over-the-Air firmware update by means of Premium FOTA Management.By embedding the RedBend vCurrent Mobile® agent, a proven and battle-tested technology powering hundreds of millions of cellular handsets world-wide, Telit is able to update its products by transmitting only a delta file, which represents the difference from one firmware version to another.Target MarketThe GE864-QUAD AUTOMOTIVE V2 is designed and developed for the usage in applications such as:• Telemetry• Telematics• Security alarms• Automated Meter Reading (AMR)• POS terminals• PDAs and Mobile Computing• Automotive and Fleet Management applicationsProduct Features• Quad-band EGSM 850 / 900 / 1800 / 1900 MHz• GSM/GPRS protocol stack 3GPP Release 4 compliant• Output power- Class 4 (2W) @ 850 / 900 MHz- Class 1 (1W) @ 1800 / 1900 MHz• Control via AT commands according to 3GPP 27.005, 27.007 and Telit custom ATcommands• Control via Remote AT commands• Event Monitor engine (ref: Event Monitor Application note)• Power consumption (typical values)- Power off: ‹ 62 uA- Idle (registered, power saving): 1.6 mA @ DRX=9• Serial port multiplexer 3GPP 27.010• SIM Application Toolkit 3GPP TS 51.014• SIM Access Profile• eCall Compliant;• Extended Supply voltage range: 3.22 – 4.5 V DC (3.8 V DC nominal)• TCP/IP stack access via AT commands• Sensitivity:≤- 107 dBm (typ.) @ 850 / 900 MHz≤- 106 dBm (typ.) @ 1800 / 1900 MHz• DARP/SAIC support• Enhanced Measurement Report support• Dimensions: 30 x 30 x 3 mm• Weight: 5 grams• Extended temperature range-40°C to +85°C (operational)-40°C to +85°C (storage temperature)• RoHS compliant• AT interface on both serial ports• Added PCM voice signal on UART• Enhanced AT Commands suite (FTP additional commands, Command mode TCP)Interfaces• 10 I/O ports maximum• Analog audio (balanced)• Digital Voice Interface• 2 A/D plus 1 D/A converters• Buzzer output• ITU-T V.24 serial link through CMOS UART:- Baud rate from 300 to 115.200 bps- Autobauding 1200 up to 115.200 bps• Two wires RS232, CMOS level (ASC1) for PYTHON debug:Audio• Telephony, emergency call• Half rate, full rate, enhanced full rate and adaptive multi rate voice codecs (HR, FR,EFR, AMR)• Superior echo cancellation & noise reduction• Multiple audio profiles pre-programmed and fully configurable by means of ATcommands (ref.: Audio Settings Application Note)• DTMFApprovals• Fully type approved conforming with R&TTE directive• CE, GCF, FCC, PTCRB, ICSMS• Point-to-point mobile originated and mobile terminated SMS• Concatenated SMS supported• SMS cell broadcast• Text and PDU mode• SMS over GPRSCircuit switched data transmission• Asynchronous non-transparent CSD up to 9.6 kbps• V.110GPRS data• GPRS class 10• Mobile station class B• Coding scheme 1 to 4• PBCCH support• GERAN Feature Package 1 support (NACC, Extended TBF)GSM Supplementary Services• Call forwarding• Call barring• Call waiting & call hold• Advice of charge• Calling line identification presentation (CLIP)• Calling line identification restriction (CLIR)• Unstructured supplementary services mobile originated data (USSD)• Closed user groupAdditional features• SIM phonebook• Fixed dialling number (FDN)• Real Time Clock• Alarm management• Network LED support• IRA, GSM, 8859-1 and UCS2 character sets• Jamming detection• Embedded TCP/IP stack, including TCP, IP, UDP, SMTP, ICMP and FTP protocols• EASY SCAN ® automatic scan over GSM frequencies (also without SIM card)Why Choose UsFAQQ1. What is the minimum order quantity for your products?A1. Minimum order quantity starts from ONE piece.Q2. What's the quality of your products?A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products.Q3. Is this product free of shipping or free samples?A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.All Categories4G 5G ModuleGPS ReceiverGPS AntennaGSM/LTE/WiFi AntennaGSM/LTE+GPS AntennaGNSS/GPS Module2G/3G/4G ModemGPS TrackerRF Coaxial / ConnectorSIMCard HolderSensorIC
