Product Description

Detailed Photos
Our C.A.G TM series Gasoline Portable Generator is powered by a reliable 439cc 16HP, single cylinder, 4-stroke OHV engine that produces a maximum power of 7500 watts at 60Hz. Its 25L fuel tank ensures over 10-hours of continuous operation at 50-percent load. Wheel kits and handle design mean the portable electric generator is easy to move in and out of storage or to new sites. This petrol generator is ideal for large RV's, power tools, trailers, bigger homes, or construction sites.
Product Description

Model	TM5500(E)	TM6500(E)	TM7500(E)	TM8500(E)	TM9500(E)	TM12000(E)
Rated output power(KW)	4	5	6	7	8	9
Max output power(KW)	4.5	5.5	6.5	7.5	8.5	10
Rated AC voltage	Single Phase/Threee Phase, 110V, 115, 127V, 208V, 220V, 230V, 240V, 380V, 400V, 415V, 440V, 460V, 480V
Frequency	50Hz
Power Factor	1
Engine model	13HP	15HP	15HP	18HP	18HP	20HP
Engine type	Single Cylinder, 4-stoke, OHV
Start system	Manual/Electric Start
Alternator material	100% Cooper, real output power
Fuel Tank Capacity	25L			25L	25L	25L
Gross Weight	76kg	80kg	85kg	88kg	92kg	95kg
Package Size	610*440*460mm

Data for CAG Gasoline Generator

• Equipped with excellent CAG gasoline engine
• 10% more efficiency,less noise and better emission
• User-friendly professional control panel
• Optional low-oil shutdown protects the generator
• Full tubular-frame protection with vibration-damping mounts
• Optional wheel-kit for easy transport
• Optional AVR and ATS available
• EU, US , AU and other receptacle for choice.
• Self-start and remoter start as an optional.
• Optional Copper/ Aluminium Alternator
• Optional Single-Phase or three phase
• Optional EMC,DC,Digital display counter
