Power Distribution Sf6 24kv 630A Gas Insulated Lbs Load Break Switch

Product Description

Product Description TSC series indoor load break switch, whose rated voltage are 12kv, 24kv and 36kv. It adopts SF6 gas as an arc extinguishing and insulation medium.
SF6 GAS is a non-inflammable gas, an inert gas and does not sustain combustion. The seal and the for-life lubrication of the rotary seals is provided by an oil film. In the MV circuit breaker field, for example,on more than 20 000 SF6 switchgear units installed by the French electrical utility (EDF), the annual fault rate related to seal problems is less than 0.05 %.
our advantages:
competitive price and good qualitypolular in power station low cost investmenthigh quality, IEC,GB standardmore than 10 years export experienceDetailed Photosthree working positions
epoxy resin enclosure
Product Parameters

Item	Unit	Value
Rated voltage	kv	24
Rated frequency	Hz	50
Rated current	A	630
Rated short time withstand current	KA	20
Rated short time duration	s	3
Rated peak withstand current	KA	50
Mechanical life	Times	More than 5000
Sf6 annual leakage rate	%	0.1

Packaging & Shipping
Company Profile Combining manufacturing experience, new technology and industrial knowledge, TENLEE aims to build advanced power distribution and protection systems.
TENLEE is specialized in manufacturing a comprehensive range of solutions from 12kv to 40.5kv for indoor/outdoor systems: gas insulated switchgears
ring main unit
sf6 free switchgears
vacuum circuit breakers
sf6 circuit breakers
reclosers
load break switches
disconnectors
distribution transformers/power transformers
substations FAQ1. What is the delivery date?
Usually within a month for a HQ.
2. Do you have tyoe tests?
Yes, we have type test in China and we also pass type test in Europe.
3. Do you have other voltage ranges?
Yes, we have 12kv, 24kv and 36kv.
