350-500kg Per Hour Automation Tongda Spinning Machinery Waste Recycling Machine

Product Description

Product display and advantages
Main Feature :
•This machine is mainly to process all kinds of waste cotton, clips, leftover, waste yarn, thread, flock and flax etc.
•This machine is TD630 opening machine combined with mode1390 cotton recycling machine, that make the best result
Product Details:
Airflow recovery instead of bamboo and rubber belt, clean,safe and anti-fireFrequency conversion instead of chain and sprocket drive,High efficiency, energy saving and environmentalprotection.
Main Feature :
•The machine body is composed of TD-1300 opening and cleaning rollers. Thhe line is improved based on rich and
advanced experience in Chinese cotton processing, which replace chains, geling by speed reducer driving to lowe happening of chains slipping and machinery parts damage greatly. Eachdriving part is equipped an speed reducer which controls
the driving system independently, so the user can adjust the speeed accordingly to the material to achieve the best opening
performance in the process.
•The adoption of air flow driving lowergreatly the happening of fire. After years of running test, the machine line is safe,-
fire-fight, high capacity,low consumption of electricity, eco-friendly and win popularity in customers by its compact design
structure.
•TD-1300 machine uses high speed centrifugal force generated by cylinder rto remove the hard impurities in wast raw material and to loosen fiber for further use after rolling up.
•The macidely used to process cotton dips, leftover waste yam, old clothes thread and flax etc.
Product Details :
•The machine line is compact in structure and easy to operate with safetyand good dust removing features. The opening
recycling line is fully enclosed, energy-saving and environmental friendly. By manual feeding, the waste material will be
placed more evenly and it is easy for labors to pick up mstuff or foreign matter in the first time to avoid damage to equipment
and fire accident. The waste recycling system is equiprear of the first opener and the drop waste material will be transported
back to condenser for further processinough the pipes by airflow. All cleaning machines are enclosed.
•The material processed by first opener will be directed to tecond opener and then material will go to the cleaning system.
Each cleaning cylinder has its separate waste material coecting pipe and all unopened material will be transported back to
the first opener by airflow for further recyding.
•Airforking method replaces the bamboo conveyor and rubber conveyor, which is tidy, safe and fire precaution. Speed
frequency control is applied instead of traditional chain-driven working. The driving part of each opener and cleaner is contrd
by frequency PRC device. Fire fighting device is fixed on each cylinder.
Dual Box Hydraulic Bale Presser
Main technical parameters

TD-1390 Opening Recycling Line
Opening machine Overal dimensions (installed safety caseLxWxH) Recycling machine Overal dimensions (installed safety case LxWxH)	7500mm×2860mm×1380mm
	8500mm×2600mm×1200mm
Weight	1500kg
Output	280-400kg/h, depending on different material
Capacity of removing impurities	6%-10%
Cylinder diameter	780-780-300-300-300-300-300-300mm
Cylinder rotation speed	960-1100-1890-1890-1890-1890-1890-1890rpm/min
Power (kw)	45-37-11-7.5-7.5-7.5-7.5-7.5kw
Wire of cylinder	Card clothing/pin/Utype
TD-1300 Opening Recycling Line
Opening machine Overal dimensions (installed safety case LxWxH) Recycling machine Overal dimensions (installed safety case LxWxH)	6280mm×2770mm×1340mm
	8500mm×2510mm×1020mm
Weight	1300kg
Output	200kg-250kg/h, depending on different material
Capacity of removing impurities	6%-10%
Cylinder diameter	620-620-250-250-250-250-250-250mm
Cylinder rotation speed	1100-1260-2050-2200-2200-2200-2200-2200rpm/min
Power (kw)	37-30-11-7.5-5.5-5.5-5.5-5.5kw
Wire of cylinder	Card clothing/pin/Utype

Parameter Comparison

TD1390	TD1300
Opening machine Overal dimensions (installed safety case LxWxH)
7500mm×2860mm×1380mm	6280mm×2770mm×1340mm
Weight
1500KG	1300KG
Rotation speed of fan
2900rpm/min	2900rpm/min
Output
280-400kg/h, depending on different material	200kg-250kg/h, depending on different material
Cylinder diameter
780-780-300-300-300-300- 300-300mm	620-620-250-250-250-250- 250-250mm
Cylinder rotation speed
960-1100-1890-1890-1890- 1890-1890-1890rpm/min	1100-1260-2050-2200-2200 -2200-2200-2200rpm/min

Mechanical Details
TD1390 Double roller opener
Patent TD-780-1390 double roller and automatic feed back opening machinesthe most advanced opening series It has the advantages of
high efficiency, energy-saving,longer fiber, lessd less damage to opened fiber.
It's mainly to process clips, leftover, waste yarn, thread and flax etc. So thamed by large customers and it's the hot product at present.
TD1300 Double roller opener
Patent TD-620-1300 double roller and automatic feed back openingmachine is the most advanced opening series.
It has the advantages of high efficiency, energy-saving.longer fiber, lessp and less damage to opened fiber. It's mainly to process clips,
leftover, waste yarn, thread and flax etc. So thawelcomed by large customers and it's the hot product at present.
TD-620 Vertical-blading cutting machine
This cutting machine adopts vertical cutting method. The waste material witransported by conveying belt to the cutting device and be cut by knives in required sizes for further recyclin
This cutter uses low speed and large torque motor. With Cycloidal reducer ed frequency control on conveying process, all parts are easy to be operated and maintained. This machine wio improve production efficiency with durable, stable and safe performance.
This cutting machine can be applied in cotton, clips, yarns, flock,polyestd other textile waste material cutting
TD-FO Fabric recyle filter system
For such textile and light industries as cotton,wool,ramie or flax,chemical fiber and tobacco etc.
