Module spare parts SEW DFS56L-TF-RH1M-KK

Product Details

Product Description

Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

SEW DFS56L-TF-RH1M-KK

SCXI-1314 ......................................................................................................777687-14 Front-mounting terminal block for the SCXI-1520 module. With factory-installed and socketed 350 quarter-bridge completion resistors for each channel. Eight 120 resistors for use with 120 quarter-bridge strain gauges are included, but not installed. It also includes two factory-installed, socketed 100 k shunt calibration resistors per channel. SCXI-1315 ......................................................................................................777687-15 8-channel front-mounting terminal block for the SCXI-1540 LVDT with six terminals for each LVDT channel – CH+, CH-, EX+, EX-, Synch, and GND. SCXI-1320 (See Figure 4) ..............................................................................777687-20 General-purpose terminal block for connecting signals to the SCXI-1120/D, SCXI-1121, SCXI-1125, and SCXI-1126 modules. It includes an onboard temperature sensor for cold-junction compensation using thermocouples, but the SCXI-1328 is recommended for precision thermocouple measurements. SCXI-1321 (See Figure 5) ..............................................................................777687-21 Adds nulling and shunt calibration to SCXI-1121 strain guage applications. With a front-panel trimming potentiometer, you can manually null out the offset voltage of bridge transducers. Each channel includes shunt calibration circuits. When activated, a switch connects a 301 k shunt resistor in parallel with the strain gauge. Both the nulling resistor and the shunt resistor are socketed for easy customization. SCXI-1322 ......................................................................................................777687-22 Terminal block required to connect signals to the SCXI-1122 module that includes an onboard temperature sensor for cold-junction compensation. SCXI-1324 ......................................................................................................777687-24 High-voltage terminal block with 48 screw terminals for the SCXI-1160 relay module. SCXI-1325 ......................................................................................................777687-25 26-screw terminal block for the SCXI-1124 module. SCXI-1326 ......................................................................................................777687-26 High-voltage terminal block with 48 screw terminals for the SCXI-1162 Series and SCXI-1163 Series modules. SCXI-1327 (See Figure 6) ..............................................................................777687-27 With the SCXI-1327 you can extend the input range of the SCXI-1120/D and SCXI-1121 to ±250 V, and extend the threshold level of the SCXI-1126 module from 5 V up to 300 V. The extended input voltage range is enabled or disabled on a per-channel basis using switches located within the SCXI-1327. The SCXI-1327 also includes an onboard temperature sensor for cold-junction compensation with thermocouples.
