China Professional Factory Drilling Cement 7" Float Collar and Float Shoe Coustomised

Product Description

China Professional Factory Drilling Cement 7 "Float Collar And Float Shoe Coustomised Product Parameters Warranty 1.5 years
Applicable Industries Energy & Mining
Weight (KG) 10
Showroom Location United States, UAE
Video outgoing-inspection Provided
Machinery Test Report Provided
Marketing Type New Product 2020
Place of Origin Shandong, China
Brand Name KY
Type Aluminum-core Spring Float Collar and Shoe
Machine Type Drilling Tool
Material Iron
Processing Type Forging
Use Well Drilling
Certification API
Product name Aluminum-core Spring Float Collar and Shoe
size 4-1/2" to 20"
Material Alloy
Machine Type Cementing Tool
MOQ 1Pcs
connection As your request
Use Well Drilling
Application Oil and gas well drilling
Color Red Product Description Product Application Types Available: Single valve and double valve are available;
Spring structure valve and ball strucuture valve are available;
Insert type and normal type are available.
Non-rotating type and normal type are available.
Type: Stab-in Type Float Collar & Float Shoe
API and ISO certified
Specifications: 4''---20''. More special sizes or combination are available as requested.
Connections Type: LTC, STC, BTC
Product Description:

Name	Size(in)	Bore O.D.(in)	Bore I.D.(in)	Min Bore Parameter(in)	Thread Type	lb(in2)
Float Collar	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626
Float Shoe	5 1/2"	6"	4 3/4"	2"	5 1/2" LCSG	4351
	7"	7 5/8"	6 1/4"	2 3/8"	7" LCSG	3626
	9 5/8"	10 5/8"	8 5/8"	2 3/8"	9 5/8" LCSG	3626
	13 3/8"	14 3/8"	12 3/8"	2 3/8"	13 3/8" LCSG	3626

Features of Stab-in Type Float Collar & Float Shoe:
a. For float shoe, the rounded nose profile helps guide the casing string.
b. The valve is made with phenolic material and molded with high strength concrete. Both of the valve and concrete are easily drillable with PDC or rock bits.
c. High strength design ensure excellent performance for flow endurance and back pressure holding.
d. Saves considerable running-in time with automatically fill up.
e. For non-rotating Float Collar & Float Shoe, the special non-rotating groove design ensures corresponding cementing plugs drilled out quickly. Detailed Photos Certifications
